Schmersal 101186156

Accessory

• Recommendation (actuator)
  • BPS 260-1 | BPS 260-2

Ambient conditions

• Ambient temperature
  • -25 ... +60 °C
• Degree of protection
  • IP67
• Protection class
  • II
• Resistance to vibrations
  • 10 … 55 Hz, amplitude 1 mm
• Restistance to shock
  • 30 g / 11 ms
• Storage and transport temperature, maximum
  • +70 °C
• Storage and transport temperature, minimum
  • -25 °C

Ambient conditions - Insulation values

• Degree of pollution
  • 3
• Overvoltage category
  • III
• Rated impulse withstand voltage U
  • 0.8 kV
• Rated insulation voltage U
  • 32 VDC

Approvals - Standards

• Certificates
  • TÜV | cULus | ASi-SaW

Electrical data - AS Interface

• AS-i Current consumption, maximum
  • 50 mA
• Rated operating voltage
  • 18 ... 31.6 VDC (Protection against polarity reversal)

Electrical data - AS-Interface specification

• AS-i, ID-Code
  • 0xB
• AS-i, ID-Code1
  • 0xF
• AS-i, ID-Code2
  • 0xE
• AS-i Input, Channel 1
  • Data bits DI 0 / DI 1 = dynamic code transmission
• AS-i Input, Channel 2
  • Data bits DI 2 / DI 3 = dynamic code transmission
• AS-i Input module address
  • 0
• AS-i, IO-Code
  • 0x0
• AS-i Outputs, DO 0 … DO 3
  • No Function
• AS-i Parameter bits, P0 ... P3
  • No function
• AS-i Profile
  • S-0.B.F.E
• AS-i Specification
  • Safety-Slave
• AS-i Version
  • V 2.1
• Note (AS-i Input module address)
  • Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
• Note (AS-i Parameter bits)
  • Set the parameter outputs to "1111" (0xF) | FID: periphery error

General data

• Enclosure material
  • Glass-fibre, reinforced thermoplastic
• Gross weight
  • 104 g
• Installation conditions (mechanical)
  • quasi-flush
• Reaction time, maximum
  • 100 ms
• Standards
  • EN IEC 62026-2 | EN ISO 13849-1 | EN IEC 60947-5-3 | EN IEC 61508
• Working principle
  • Magnetic drive

General data - Features

• Coding
  • Yes
• Integral system diagnostics, status
  • Yes

Mechanical data

• Actuating element
  • Magnet
• Direction of motion
  • Head-on to the active surface
• Door hinge
  • Left
• Note (Repeat accuracy R)
  • Wiederholgenauigkeit R ≤ 0,1 x S

Mechanical data - Connection technique

• Length of cable
  • 2 m
• Material of the Cable mantle
  • LSYY
• Termination
  • Connecting cable with M12 connector, straight, 4-pole
• Wire cross-section
  • 0.23 mm
  • 23 AWG

Mechanical data - Dimensions

• Height of sensor
  • 26 mm
• Length of sensor
  • 13 mm

Mechanical data - Switching distances according EN IEC 60947-5-3

• Assured switching distance "OFF" S
  • 15 mm
• Assured switching distance "ON" S
  • 5 mm
• Note (Switching distance Sn)
  • Axial misalignment, a horizontal and vertical misalignment of the safety sensor and the actuator are tolerated. The possible misalignment depends on the distance of the active surfaces of the sensor and the actuator. The sensor remains active within the tolerance range.

Pin assignment

• PIN 1
  • AS-i +
• PIN 2
  • n.c.
• PIN 3
  • AS-Interface -
• PIN 4
  • n.c.

Safety classification

• Category
  • 4
• Mission time
  • 20 Year(s)
• Note (PFH-value)
  • up to max. 500,000 switching cycles/year
• Performance Level, up to
  • e
• PFH value
  • 6.21 x 10⁻⁹ /h
• Safety Integrity Level (SIL), suitable for applications in
  • 3
• Standards
  • EN IEC 61508

Scope of delivery

• Scope of delivery
  • Actuator must be ordered separately.

Status indication

• Note (LED switching conditions display)
  • (1) LED green: Supply voltage | (2) red LED: AS-i communication error / Slave address = 0
