Schmersal 101168060
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
ZS 231-01YR-M16-1256
Schmersal 101168060 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Ambient temperature
- -30 ... +80 °C
- Degree of protection
- IP65
Ambient conditions - Insulation values
- Rated insulation voltage U
- 500 V
Electrical data
- Bounce duration, maximum
- 3 ms
- Material of the contacts, electrical
- Silver
- Switching element
- Opener (NC)
- Switching frequency
- 5,000 /h
- Switching principle
- Magnet Snap Action
- Switchover time, maximum
- 5 ms
- Thermal test current
- 10 A
- Utilisation category AC-15
- 230 VAC
- 4 A
- Utilisation category DC-13
- 4 A
- 24 VDC
General data
- Enclosure material
- Glass-fibre reinforced thermoplastic, self-extinguishing
- Gross weight
- 55 g
- Standards
- DIN VDE 0660-200 | EN 81 | EN IEC 60947-5-1
General data - Features
- Number of normally closed (NC)
- 1
- Number of safety contacts
- 1
- Safety functions
- Yes
Mechanical data
- Actuating force, approx.
- 6 N
- Actuating speed
- 10 mm/min
- Contact opening
- 2 mm
- Note (Switchover time)
- Switchover time in accordance with actuating speed
Mechanical data - Connection technique
- Cable section, maximum
- 2.5 mm²
- Cable section, minimum
- 0.75 mm²
- Termination
- Screw terminals M20 x 1.5
Mechanical data - Dimensions
- Height of sensor
- 72 mm
- Length of sensor
- 31 mm
- Width of sensor
- 30 mm
Safety classification - Safety outputs
- B
- 20,000,000 Operations
