Schmersal 101126707
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
DIM 1.2 24 VAC/DC
Schmersal 101126707 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Degree of protection of clips or terminals
- IP20
- Degree of protection of the enclosure
- IP40
- Resistance to vibrations
- 10...55 Hz, Amplitude 0.35 mm, ± 15 %
- Restistance to shock
- 10 g / 11 ms
Electrical data
- Rated control voltage
- 24 VAC/DC
- Rated supply frequency, maximum
- 60 Hz
- Rated supply frequency, minimum
- 50 Hz
Electrical data - Digital inputs
- Input signal, HIGH Signal "1"
- 10 V…Ua
- Input signal, LOW Signal "0"
- 0 V…3 V
Electrical data - Digital Output
- Design of control elements
- relay with potential-free change-over contact
- Output current, maximum
- 150 mA
Electrical data - Relay outputs
- Current, Utilisation category AC-1
- 5 A
- Current, Utilisation category DC-13
- 3 A
- Switching capacity, maximum
- 250 VAC
- Voltage, Utilisation category AC-1
- 250 VAC
- Voltage, Utilisation category DC-13
- 24 VDC
General data
- Enclosure material
- Glass-fibre, reinforced thermoplastic
- Gross weight
- 192 g
General data - Features
- Number of relay outputs (1-channel)
- 2
Mechanical data
- Mounting
- For two mounting holes to DIN 43660 or snaps onto standard DIN rail to DIN EN 50022
Mechanical data - Connection technique
- Cable section, maximum
- 4 mm²
- Note (Cable section)
- All indications including the conductor ferrules.
- Termination
- Screw terminals M20 x 1.5
Mechanical data - Dimensions
- Height
- 110 mm
- Width
- 55 mm
Specifications
- Height
- 110 mm
- Length
- 75 mm
- Width
- 55 mm
