Schmersal 101061101
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TZ 471-21/21Y
Schmersal 101061101 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Ambient temperature
- -30 ... +90 °C
- Degree of protection
- IP65
Ambient conditions - Insulation values
- Rated insulation voltage U
- 500 V
Approvals - Standards
- Certificates
- cULus | CCC
Electrical data
- Material of the contacts, electrical
- Silver
- Note (Switching element)
- with double break
- Switching element
- NO contact / NC contact
- Switching frequency
- 1,000 /h
- Switching principle
- Slow action
- Thermal test current
- 25 A
General data
- Enclosure coating material
- painted
- Enclosure material
- Grey cast iron, galvanised
- Gross weight
- 4,910 g
- Standards
- EN IEC 60947-5-1
- Working principle
- mechanical
General data - Features
- Number of NC, left
- 1
- Number of NC, right
- 1
- Number of NO, left
- 2
- Number of NO, right
- 2
Mechanical data
- Actuating element
- Pull lever
- Actuating speed, maximum
- 3 m/s
- Actuating speed, minimum
- 0.1 mm/min
- Actuation direction
- Each time 75° right-hand side and left-hand side rotation
- Contact opening
- 2 x 4 mm
- Mechanical life, minimum
- 1,000,000 Operations
Mechanical data - Dimensions
- Height of sensor
- 123 mm
- Length of sensor
- 158 mm
- Width of sensor
- 250 mm
Safety classification - Safety outputs
- B
- 2,000,000 Operations
