Phoenix Contact 2862178
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Inline, Relay terminal, Relay output: 1 (floating contacts), 24 V DC / 230 V AC, 2.6 A, for switching inductive and capacitive loads, transmission speed in the local bus: 500 kbps, degree of protection: IP20, including Inline connector and labeling fieldInline terminal - IB IL 24/230 DOR1/W-PC-PAC - 2862178
Phoenix Contact 2862178 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Air pressure (operation)
- 70 kPa - 106 kPa (up to 3000 m above sea level)
- Air pressure (storage/transport)
- 70 kPa - 106 kPa (up to 3000 m above sea level)
- Ambient temperature (operation)
- -25 °C - 55 °C
- Ambient temperature (storage/transport)
- -25 °C - 85 °C
- Degree of protection
- IP20
- Permissible humidity (operation)
- 10 % - 95 % (non-condensing)
- Permissible humidity (storage/transport)
- 10 % - 95 % (non-condensing)
Digital outputs
- Connection method
- Spring-cage connection
- Maximum output current per channel
- 2.6 A
- Maximum output current per module
- 2.6 A
- Nominal output voltage
- 24 V DC
- 230 V AC
- Number of outputs
- 1 (floating contacts)
- Output description
- SPDT relay contact
- Output name
- Relay output
Dimensions
- Depth
- 71.5 mm
- Height
- 119.8 mm
- Note on dimensions
- Housing dimensions
- Width
- 12.2 mm
Electrical isolation
- Test section
- Contact / PE 1 kV 50 Hz 1 min.
- Contact/contact 1 kV 50 Hz 1 min.
- Relay contact / Bus logics 4 kV 50 Hz 1 min.
Environmental Product Compliance
- China RoHS
- No hazardous substances above threshold values
- Environmentally friendly use period: unlimited = EFUP-e
Inline potentials
- Current consumption
- max. 60 mA
- Designation
- Communications power (UL)
- Power consumption
- max. 0.45 W
- Supply voltage
- 7.5 V DC (via voltage jumper)
Interfaces
- Connection method
- Inline data jumper
- Designation
- Inline local bus
- No. of channels
- 2
- Transmission speed
- 500 kbps
Note
- Utilization restriction
- EMC: class A product, see manufacturer's declaration in the download area
Relay outputs
- Contact type
- 1 floating PDT
- Limiting continuous current
- 2.6 A
- Mechanical service life
- 2x 10⁷ cycles
- Switching capacity
- max. 750 VA (see to derating)
- Switching current
- max. 2.6 A (At 30 V DC)
- max. 0.15 A (for 250 V DC)
- Switching voltage
- max. 250 V DC
- max. 253 V AC
Standards and Regulations
- Connection in acc. with standard
- CUL
- Protection class
- I (МЭК 61140, EN 61140, VDE 0140-1)
