Phoenix Contact 2861548
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Inline, Digital input terminal, Digital inputs: 1, 230 V AC, connection method: 3-wire, transmission speed in the local bus: 500 kbps, degree of protection: IP20, including Inline connector and labeling fieldInline terminal - IB IL 230 DI 1-PAC - 2861548
Phoenix Contact 2861548 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Air pressure (operation)
- 80 kPa - 160 kPa (up to 2000 m above sea level)
- Air pressure (storage/transport)
- 70 kPa - 106 kPa (up to 3000 m above sea level)
- Ambient temperature (operation)
- -25 °C - 55 °C
- Ambient temperature (storage/transport)
- -25 °C - 85 °C
- Degree of protection
- IP20
- Permissible humidity (operation)
- 75 % - 85 % (in the range of -25°C - +55°C, appropriate measures against increased humidity (> 85%) must be taken.)
- Permissible humidity (storage/transport)
- 75 % - 85 % (slight temporary condensation may sometimes appear on the housing)
Digital inputs
- Connection method
- Spring-cage connection
- Connection technology
- 3-wire
- Description of the input
- IEC 61131-2 type 1
- Input name
- Digital inputs
- Input voltage
- 230 V AC
- Input voltage range "0" signal
- 0 V AC - 40 V AC
- Input voltage range "1" signal
- 164 V AC - 253 V AC
- Nominal input current at UIN
- 6.11 mA (at nominal voltage)
- Nominal input voltage UIN
- 230 V AC
- Number of inputs
- 1
Dimensions
- Depth
- 71.5 mm
- Height
- 119.8 mm
- Width
- 12.2 mm
Electrical isolation
- Test section
- 5 V supply, outgoing remote bus/7.5 V supply (bus logics) 500 V AC 50 Hz 1 min.
- 7.5 V supply (bus logics) / I/O area 2500 V AC 50 Hz 1 min.
- Routine test 1200 V AC 50 Hz 1 min.
- 5 V supply, incoming remote bus/7.5 V supply (bus logics) 500 V AC 50 Hz 1 min.
Environmental Product Compliance
- China RoHS
- For details about hazardous substances go to tab 'Downloads', Category 'Manufacturer's declaration'
- Environmentally Friendly Use Period = 50 years
Inline potentials
- Current consumption
- 0.25 A
- max. 0.25 A
- max. 30 mA
- Designation
- I/O supply
- Communications power (UL)
- Supply voltage
- 7.5 V DC (via voltage jumper)
- 230 V AC (via voltage jumper)
- 230 V AC
Interfaces
- Connection method
- Inline data jumper
- Designation
- Inline local bus
- No. of channels
- 2
- Transmission speed
- 500 kbps
Note
- Utilization restriction
- EMC: class A product, see manufacturer's declaration in the download area
Power supply for module electronics
- Supply voltage
- 230 V AC
- Supply voltage range
- 12 V AC - 253 V AC
Standards and Regulations
- Connection in acc. with standard
- CUL
- Protection class
- I (МЭК 61140, EN 61140, VDE 0140-1)
