Description
Interface converter, for converting RS-232 to TTY, two channels, with electrical isolation, DIN-rail mountableInterface converter 2761253
Phoenix Contact 2761253 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Ambient temperature (operation)
- 0 °C - 50 °C
- Degree of protection
- IP20
Dimensions
- Depth
- 110 mm
- Height
- 75 mm
- Width
- 45 mm
Environmental Product Compliance
- China RoHS
- For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”
- Environmentally Friendly Use Period = 50
- REACh SVHC
- Lead 7439-92-1
Note
- Utilization restriction
- EMC: class A product, see manufacturer's declaration in the download area
Power supply
- Nominal supply voltage
- 24 V DC ±20 %
- Typical current consumption
- 130 mA (24 V DC)
Serial interface
- Conductor cross section AWG max.
- 14
- 14
- Conductor cross section AWG min.
- 24
- 24
- Conductor cross section flexible max.
- 2.5 mm²
- 2.5 mm²
- Conductor cross section flexible min.
- 0.2 mm²
- 0.2 mm²
- Conductor cross section solid max.
- 2.5 mm²
- Conductor cross section solid min.
- 0.2 mm²
- Connection method
- D-SUB 9 plug
- Pluggable screw connection
- Pluggable screw connection
- D-SUB-9 female connector
- Interface 1
- V.24 (RS-232) interface in acc. with ITU-T V.28, EIA/TIA-232, DIN 66259-1
- Interface 2
- TTY interface, CL2 in acc. with DIN 66348-1
- Load/output load current output
- ≤ 500 Ω
- Operating mode
- Active, semi active, passive
- Serial transmission speed
- ≤ 19.2 kbps
- ≤ 19.2 kbps
- Transmission length
- ≤ 1000 m (twisted pair)
- ≤ 15 m (twisted pair)
Standards and Regulations
- Electromagnetic compatibility
- Conformance with EMC Directive 2014/30/EU
- Noise emission
- EN 55022 / Class B
