Phoenix Contact 2702133
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Inline XC, Digital output terminal, Digital outputs: 2, 24 V DC, 2 A, connection method: 4-wire, Extreme conditions version, transmission speed in the local bus: 500 kbps, degree of protection: IP20, including Inline connector and labeling fieldInline terminal 2702133
Phoenix Contact 2702133 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Air pressure (operation)
- 70 kPa - 106 kPa (up to 3000 m above sea level)
- Air pressure (storage/transport)
- 70 kPa - 106 kPa (up to 3000 m above sea level)
- Ambient temperature (operation)
- -25 °C - 55 °C
- -40 °C - 70 °C (Extended, see section “Tested successfully: use under extreme ambient conditions” in the data sheet.)
- Ambient temperature (storage/transport)
- -40 °C - 85 °C
- Degree of protection
- IP20
- Permissible humidity (operation)
- 10 % - 95 % (non-condensing)
- Permissible humidity (storage/transport)
- 10 % - 95 % (non-condensing)
Connection data
- Conductor cross section AWG max.
- 16
- Conductor cross section AWG min.
- 28
- Conductor cross section flexible max.
- 1.5 mm²
- Conductor cross section flexible min.
- 0.08 mm²
- Conductor cross section solid max.
- 1.5 mm²
- Conductor cross section solid min.
- 0.08 mm²
- Connection method
- Spring-cage connection
- Designation
- Inline connector
- Stripping length
- 8 mm
Digital outputs
- Connection method
- Spring-cage connection
- Connection technology
- 4-wire
- Maximum output current per channel
- 2 A
- Maximum output current per module
- 4 A
- Nominal load, inductive
- 48 VA (1,2 H, 12 Ω)
- Nominal load, lamp
- 48 W
- Nominal load, ohmic
- 48 W (12 Ω)
- Nominal output voltage
- 24 V DC
- Number of outputs
- 2
- Output name
- Digital outputs
- Output voltage
- 24 V DC (US - 1 V)
- Type of protection
- Overload protection, short-circuit protection of outputs
Dimensions
- Depth
- 71.5 mm
- Height
- 119.8 mm
- Note on dimensions
- Housing dimensions
- Width
- 12.2 mm
Electrical isolation
- Test section
- 7.5 V supply (bus logics) / functional earth ground 500 V AC 50 Hz 1 min.
- 24 V supply (I/O) / functional earth ground 500 V AC 50 Hz 1 min.
- 7.5 V supply (bus logics)/24 V supply (I/O) 500 V AC 50 Hz 1 min.
Environmental Product Compliance
- China RoHS
- No hazardous substances above threshold values
- Environmentally friendly use period: unlimited = EFUP-e
Inline potentials
- Current consumption
- max. 4 A
- max. 35 mA
- 0 A
- Designation
- Segment circuit supply (US)
- Communications power (UL)
- Power consumption
- max. 0.27 W
- Supply voltage
- 7.5 V DC (via voltage jumper)
- 24 V DC (via voltage jumper)
- Supply voltage range
- 19.2 V DC - 30 V DC (including all tolerances, including ripple)
Interfaces
- Connection method
- Inline data jumper
- Designation
- Inline local bus
- No. of channels
- 2
- Transmission speed
- 500 kbps
Note
- Utilization restriction
- EMC: class A product, see manufacturer's declaration in the download area
Standards and Regulations
- Connection in acc. with standard
- CUL
- Protection class
- III, IEC 61140, EN 61140, VDE 0140-1
