Description
PCB connector, nominal current: 12 A, nominal cross section: 2.5 mm², number of positions: 12, pitch: 5.08 mm, connection method: Push-in spring connection, color: green, contact surface: TinPrinted-circuit board connector - FKC 2,5/12-ST-5,08-RF EX - 1796209
Phoenix Contact 1796209 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Connection capacity
- 2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve
- 0.5 mm² - 1.5 mm²
- Conductor cross section AWG / kcmil
- 24 - 12
- Conductor cross section flexible
- 0.2 mm² - 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve
- 0.25 mm² - 2.5 mm²
- Conductor cross section, flexible, with ferrule, with plastic sleeve
- 0.25 mm² - 2.5 mm²
- Conductor cross section solid
- 0.2 mm² - 2.5 mm²
- Connection method
- Push-in spring connection
- pluggable
- Yes
- Stripping length
- 10 mm
Dimensions for the product
- Height [ h ]
- 15 mm
- Length [ l ]
- 25.73 mm
- Pitch
- 5.08 mm
- Width [ w ]
- 73.88 mm
Electrical parameters
- Nominal current
- 12 A
- Nom. voltage
- 176 V
- Rated current
- 12 A
Environmental Product Compliance
- China RoHS
- No hazardous substances above threshold values
- Environmentally friendly use period: unlimited = EFUP-e
Flange specifications
- Mounting flange
- Self-locking flange
- Type of locking
- Snap-in locking
General product information
- Note
- In accordance with IEC 61984, COMBICON connectors have no switching power (COC). During designated use, they must not be plugged in or disconnected when carrying voltage or under load.
Item properties
- Brief article description
- PCB connector
- Connection method
- Push-in spring connection
- Locking
- without
- Number of connections
- 12
- Number of levels
- 1
- Number of positions
- 12
- Number of potentials
- 12
- Pitch
- 5.08 mm
- Plug-in system
- CLASSIC COMBICON (EX)
- Range of articles
- FKC 2,5/..-ST-RF-EX
- Type of contact
- Female connector
Material data – actuating element
- CTI according to IEC 60112
- 600
- Flammability rating according to UL 94
- V0
- Insulating material
- PBT
Material data - contact
- Contact material
- Cu alloy
- Metal surface contact area (top layer)
- Tin (4 - 8 µm Sn)
- Metal surface terminal point (top layer)
- Tin (4 - 8 µm Sn)
- Note
- WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
- Surface characteristics
- hot-dip tin-plated
Material data - housing
- CTI according to IEC 60112
- 600
- Flammability rating according to UL 94
- V0
- Glow wire flammability index GWFI according to EN 60695-2-12
- 850
- Glow wire ignition temperature GWIT according to EN 60695-2-13
- 775
- Housing color
- green (6021)
- Insulating material
- PA
- Insulating material group
- I
- Temperature for the ball pressure test according to EN 60695-10-2
- 125 °C
Packaging information
- Denomination packing units
- Pcs.
- Pieces per package
- 50
- Type of packaging
- packed in cardboard
