Panduit PFL6X04BU-CEG
Free Shipping
1 Year Warranty
A+ Rated On The BBB
Next Day Delivery
Based In The USA
Description
The TX6A™ Cat 6A shielded F/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by an overall metallic foil shield within a HDPE flame-retardant jacket. The blue, LSZH (IEC 60332-3) cable is supplied 305 meters (1,000 feet) to a reel.Copper Cable, Cat 6A, 23 AWG, F/UTP, LSZH-3, Blue
Panduit PFL6X04BU-CEG is now available new, surplus, and used from Williams Automation.
If you need a specific firmware or series relating to this item, please call or email us with your request.
We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you require one.
Please note we offer UPS Next Day Air shipping for all orders. Please be sure to select next day shipping at checkout, and we will provide same-day shipment.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Packaging Details
- ARRA Compliant
- N
- Country of Origin 2Digit
- CN
- EAN
- 00074983332731
- GTIN Carton
- 50074983332736
- GTIN Package
- 00074983332731
- Hazardous Material Flag
- N
- Mercury Content Indicator
- No
- Min Order Qty
- 18
- Min. Order UOM
- Roll
- Pallet Quantity
- 18
- Pallet Volume
- 39.111111
- Pallet Weight
- 770.4000
- REACH Status
- False
- RoHS Compliant
- Compliant
- Standard Carton Volume Ft3
- 39.1111
- Standard Carton Weight Pounds
- 770.4000
- Standard Package Volume Ft3
- 2.1728
- Standard Package Weight Pounds
- 42.8000
- Std Carton Height In
- 44
- Std Carton Height MM
- 1117.6
- Std Carton Length In
- 48
- Std Carton Length MM
- 1219.2
- Std Carton Width In
- 32
- Std Carton Width MM
- 812.8
- Std Ctn Qty
- 18
- Std Package Height In
- 12.6
- Std Package Height MM
- 320.04
- Std Package Length In
- 15.75
- Std Package Length MM
- 400.05
- Std Package Width In
- 15.75
- Std Package Width MM
- 400.05
- Std. Pkg. Qty.
- 1
- Std. Pkg. UOM
- Roll
- UOM EA PK
- EA
- UPC
- 07498333273
Specifications
- Acidity Rating
- a1
- Bend Radius (In.)
- 1.15
- Bend Radius (mm)
- 29.2
- Cable Construction
- F/UTP
- Color
- Blue
- Conductor Gauge (AWG)
- 23
- Conductor Gauge (mm)
- 0.57
- Conductor Material
- Copper
- Conductor Type
- Solid
- Environment
- Indoor
- EuroClass Flame Rating
- Dca
- EuroClass Rating
- Dca-s2,d2,a1
- Flaming Droplets Rating
- d2
- Flammability Rating
- LSZH-3 (IEC 60332-3)
- Insulation Diameter (In.)
- 0.04
- Insulation Diameter (mm)
- 1.12
- Insulation Material
- PE
- Jacket Material
- High Density Polyethylene
- Maximum Installation Temperature (°C)
- 75
- Maximum Installation Temperature (°F)
- 167
- Maximum Installation Tension (lb)
- 25
- Maximum Installation Tension (N)
- 110
- Maximum Operating Temperature (°C)
- 75
- Maximum Operating Temperature (°F)
- 167
- Maximum Voltage (V)
- 80
- Minimum Installation Temperature (°C)
- 0
- Minimum Installation Temperature (°F)
- 32
- Minimum Operating Temperature (°C)
- -20
- Minimum Operating Temperature (°F)
- -4
- Nominal Cable Outside Diameter (In.)
- 0.28
- Nominal Cable Outside Diameter (mm)
- 7.3
- Note
- Available in Asia Pacific, EMEA and Latin America
- Number of Pairs
- 4
- Overall Length (ft.)
- 1000
- Overall Length (m)
- 305
- Packaging Type
- Reel
- Performance Level
- Category 6A
- Product Segment
- DEFAULT
- Product Type
- Copper Cable
- Resistance Properties
- Flame-Resistant
- Smoke Rating
- s2
- Standards Met
- Exceeds the requirements of ISO 11801 Class EA and ANSI/TIA-568-C.2 Category 6A standards; Standards Compliance: UL Listed CMP-LP 0.7A and CMR-LP 0.5A; PoE compliance: Meets IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt for PoE applications; CE Compliant: Euroclass Dca-s2-d2-a1; RoHS Compliant
- Sub Brand
- Pan-Net®
