Panduit LCMB50-12-E
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
One-hole, metric conductor, long barrel, 50mm² 2r, 35mm² class 5f/6f, M12 stud hole.Copper Compression Metric Lug, 1 Hole, Long Barrel, 50mm² 2r, 35mm² 5f/6f, M12 Stud
Panduit LCMB50-12-E is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Additional Specifications
- Angle
- Straight
- Barrel I.D. (mm)
- 9.8
- Barrel Length (mm)
- 36.6
- Barrel Style
- Long
- Barrel Type
- Long Barrel Length without Inspection Window
- Conductor Material
- Copper
- Copper Conductor Size Class 2 (mm2)
- 50
- Copper Conductor Size Class 5F (mm²)
- 35
- Copper Conductor Size Class 6F (mm²)
- 35
- Country of Origin 2Digit
- IN
- Country of Origin Description
- India
- Gross Volume UOM
- CU
- Hazardous Material Flag
- N
- Lowest Level UOM
- EA
- Master Pack Packaging Description
- BOX
- Master Pack Quantity
- 1
- NMFC Rate
- 70
- Palm Width (mm)
- 23
- Panduit Die Index No.
- P37
- Panduit Indenter Die Index No.
- —
- Panduit Nest Die Index No.
- —
- Part Number Series
- LCMB
- Parts Available
- N
- Plating Type
- Tin Plated
- Product Group Assignment
- Power Connectors
- Shelf Life
- 0
- Stud Hole Size (mm)
- M12
- Stud Set Back (mm)
- 11
- Temperature Rating
- 90°C
- Tongue Thickness (mm)
- 1.8
- Unit Volume
- .002083
- Unit Weight
- .046
- UNSPSC
- 39121405
- UOM EA Pk
- PK
- Wire Strip Length (mm)
- 38.2
- Wrench Clearance (mm)
- 14
Certifications & Approvals
- American Bureau Shipping Approved
- Yes
- ARRA Compliant
- Y
- Buy American Compliant
- Y
- CE Compliant
- Yes
- CSA Certified
- C22.2 No. 65-13
- ECCN Commodity Code
- EAR99
- MSDS Indicator
- N
- Ozone Depleting Compounds
- N
- RoHS Compliancy Status
- Compliant
- Standards
- Meets EN 61238-1:2003/IEC 61238-1:2003 Class B
- Tin-Plating Meets ASTM B545-97, Class C
- 320µ in (8µ m)
- UL and CSA Temperature Rating
- 90° C
- UL and CSA Voltage Rating
- 35kV
- UL Listed
- 486A-486B File #E52164
Packaging Details
- GTIN Package
- 30074983640899
- Minimum Order Quantity
- 20
- Part Number Full UPC
- 7498364089
- Sell Pack Packaging Description
- BOX
- Sell Pkg Qty 1
- 1
- Ship Pack Packaging Description
- BOX
- Stanard Carton Quantity
- 0
- Standard Carton Weight
- 0
- Standard Package Quantity
- 20
- Standard Package Weight
- 0.92
- Std Package Height
- 3
- Std Package Height MM
- 76.2
- Std Package Length
- 8
- Std Package Length MM
- 203.2
- Std Package Width
- 3
- Std Package Width MM
- 76.2
- UNSPSC Package Description
- PACKAGE
- UNSPSC Package UOM
- PK
- UNSPSC Piece Desription
- EACH
- UNSPSC Piece UOM
- EA
Specifications
- Brand Name
- Panduit
- Length (mm)
- 66.3
- Material
- High conductivity seamless copper tube
- Order Min Qty Each
- 1
- Order Multiple Quantity Each
- 1
- Sub Brand
- Type LCMB
