Panduit DPF18-110FIB-C
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
The vibration resistant DiscoGrip™ female disconnect is made of brass and is tin-plated. It is fully insulated in red premium nylon housing. It has a tab size of 0.110 x 0.032" (2.8 x 0.8 mm) and supports a wire range of 22-18 AWG (0.5-1.0 mm²). It is 0.71" (18 mm) long and 0.19" (4.8 mm) wide. The disconnect has a funnel entry barrel configuration and a butted seam barrel. It comes in bottles of 100.Disco-Grip™ DPF18-110FIB-C Loose Piece Disconnect
Panduit DPF18-110FIB-C is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Packaging Details
- ARRA Compliant
- Y
- Country of Origin 2Digit
- MX
- EAN
- 00074983203680
- GTIN Carton
- 50074983203685
- GTIN Package
- 00074983203680
- Hazardous Material Flag
- N
- Mercury Content Indicator
- No
- Min Order Qty
- 100
- Min. Order UOM
- Piece
- REACH Status
- False
- RoHS Compliant
- Compliant
- Standard Carton Volume Ft3
- 0.0764
- Standard Carton Weight Pounds
- 1.4000
- Standard Package Volume Ft3
- 0.0076
- Standard Package Weight Pounds
- 0.1400
- Std Carton Height In
- 3.7
- Std Carton Height MM
- 93.98
- Std Carton Length In
- 10.2
- Std Carton Length MM
- 259.08
- Std Carton Width In
- 3.5
- Std Carton Width MM
- 88.9
- Std Ctn Qty
- 1000
- Std Package Height In
- 3.6
- Std Package Height MM
- 91.44
- Std Package Length In
- 1.9
- Std Package Length MM
- 48.26
- Std Package Width In
- 1.9
- Std Package Width MM
- 48.26
- Std. Pkg. Qty.
- 100
- Std. Pkg. UOM
- Piece
- UOM EA PK
- PK
- UPC
- 07498320368
Specifications
- Barrel Type
- Funnel
- Base Material
- Brass
- Color Code
- Red
- Disconnect Type
- Female Disconnect-Right Angle
- Finish/Coating
- Tin-Plated
- Flammability Rating
- UL94V-2/UL94-HB
- For Use With
- CT-1525, CT-2300/ST (CD-525), CT-2500/L (CT-2525CH), UP14ZLW (CD-525)
- Insulation Diameter (In.)
- 0.13
- Insulation Diameter (mm)
- 3.4
- Insulation Material
- Premium Nylon
- Insulation Type
- Fully Insulated
- Maximum Copper Conductor Size (AWG)
- #18
- Maximum Metric Conductor Size (mm²)
- 1
- Maximum Operating Temperature (°C)
- 105
- Maximum Operating Temperature (°F)
- 221
- Maximum Voltage (kV)
- 0.6
- Maximum Voltage (V)
- 600
- Maximum Wire Insulation Diameter (In.)
- 0.13
- Maximum Wire Insulation Diameter (mm)
- 3.4
- Maximum Wire Size (AWG)
- #18
- Minimum Copper Conductor Size (AWG)
- #22
- Minimum Metric Conductor Size (mm²)
- 0.5
- Minimum Wire Size (AWG)
- #22
- Overall Height (In.)
- 0.16
- Overall Height (mm)
- 4.1
- Overall Length (In.)
- 0.71
- Overall Length (mm)
- 18
- Overall Thickness (In.)
- 0.1
- Overall Thickness (mm)
- 2.5
- Overall Width (In.)
- 0.19
- Overall Width (mm)
- 4.8
- Packaging Type
- Bottle
- Product Segment
- IEI
- Product Type
- Disconnect
- Seam Type
- Butted
- Standards Met
- UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
- Sub Brand
- Disco-Grip™
- Tab Size (In.)
- 0.110 x 0.032
- Tab Size (mm)
- 2.8 x 0.8
- Tongue Angle
- Straight
- Wire Strip Length (In.)
- 1932-09-01
- Wire Strip Length (mm)
- 7.1
