Description
The vibration resistant female disconnect compressor is made of brass and is tin-plated. It is fully insulated in yellow, nylon housing. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 12-10 AWG (4.0-6.0 mm²). It is 0.96" (24.4 mm) long and 0.35" (8.9 mm) wide. The disconnect has a funnel entry barrel configuration and a butted seam barrel. It comes in reels of 2000.Reel Smart™ DNF10250FIBC-2K Disconnects, Yellow, Vinyl, 10-12 AWG, 0.25" Tab
Panduit DNF10250FIBC-2K is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Packaging Details
- ARRA Compliant
- Y
- Country of Origin 2Digit
- MX
- EAN
- 00074983829071
- GTIN Package
- 00074983829071
- Hazardous Material Flag
- N
- Mercury Content Indicator
- No
- Min Order Qty
- 2,000
- Min. Order UOM
- Piece
- Pallet Quantity
- 32,000
- Pallet Weight
- 145.6000
- REACH Status
- False
- RoHS Compliant
- Compliant
- Standard Package Volume Ft3
- 0.8961
- Standard Package Weight Pounds
- 9.1000
- Std Package Height In
- 2.4
- Std Package Height MM
- 60.96
- Std Package Length In
- 25.4
- Std Package Length MM
- 645.16
- Std Package Width In
- 25.4
- Std Package Width MM
- 645.16
- Std. Pkg. Qty.
- 2000
- Std. Pkg. UOM
- Piece
- UOM EA PK
- PK
- UPC
- 07498382907
Specifications
- Barrel Type
- Funnel
- Base Material
- Brass
- Color Code
- Yellow
- Disconnect Type
- Female Disconnect-Compressor
- Finish/Coating
- Tin-Plated
- Flammability Rating
- UL94-HB
- For Use With
- Crimp press with CA9 (CD9-13B) or CA-800EZ (CD-800-13) applicator
- Insulation Diameter (In.)
- 0.22
- Insulation Diameter (mm)
- 5.6
- Insulation Material
- Nylon
- Insulation Type
- Fully Insulated
- Maximum Copper Conductor Size (AWG)
- #10
- Maximum Metric Conductor Size (mm²)
- 6
- Maximum Operating Temperature (°C)
- 105
- Maximum Operating Temperature (°F)
- 221
- Maximum Voltage (kV)
- 0.6
- Maximum Voltage (V)
- 600
- Maximum Wire Insulation Diameter (In.)
- 0.22
- Maximum Wire Insulation Diameter (mm)
- 5.6
- Maximum Wire Size (AWG)
- #10
- Minimum Copper Conductor Size (AWG)
- #12
- Minimum Metric Conductor Size (mm²)
- 4
- Minimum Wire Size (AWG)
- #12
- Overall Length (In.)
- 0.96
- Overall Length (mm)
- 24.4
- Overall Width (In.)
- 0.35
- Overall Width (mm)
- 8.9
- Packaging Type
- Reel
- Product Segment
- IEI
- Product Type
- Disconnect
- Seam Type
- Butted
- Sub Brand
- Reel Smart™
- Tab Size (In.)
- 0.250 x 0.032
- Tab Size (mm)
- 6.3 x 0.8
- Tongue Angle
- Straight
- Wire Strip Length (In.)
- 1932-09-01
- Wire Strip Length (mm)
- 7.1
