nVent DT2C32011R
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
DIN rail mounted Surge Protection Device that provides protection against voltage transients in IEC Class II, 1+1 Mode environments. 1+1 Mode, 230 V Un.DT2C Compact Surge Protection Class II, 1+1 Mode, 230 V Un
nVent Erico DT2C32011R is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Back-Up Fuse @ Isccr
- 63 A @ 25 kA
- Complies With
- IEC® 61643-11 Class II
- Depth (D)
- 68-68.00
- Distribution System
- TT
- Enclosure Material
- UL® 94V-0 Thermoplastic
- Enclosure Rating
- IP 20
- Follow Current Interrupt Rating (Ifi)
- 0.1
- Height (H)
- 90-90.00
- Humidity
- 5-95.00
- Max Continuous Operating Voltage (Uc)
- 320 VAC L-N
- Max Discharge Current (Imax), IEC
- 35
- Mounting
- 35 mm top hat DIN rail
- Nominal Discharge Current (In), IEC
- 15
- Nominal System Voltage (Un)
- 230 V
- Protection Modes
- L-N
- Remote Contacts
- Yes
- Remote Contact Switching Capacity
- 0.5 A @ 250 VAC
- Short Circuit Current Rating (Isccr)
- 25
- Status Indication
- Mechanical flag
- Technology
- Thermal Disconnect
- Temperature
- -40-85.00
- Temporary Over Voltage Withstand 200 ms (Ut), N-PE
- 1,200
- Temporary Over Voltage Withstand 5 s (Ut), L-N
- 335
- Unit Weight
- 0.13-0.13
- Voltage Protection Level (Up)
- 1,500
- Weight
- 0.13 kilogram
- Width (W)
- 18-18.00
