NOSHOK 25-210-10-inH2O

Specifications

• Accuracy
  • 1.6 %
• Ambient Temperature Range
  • -20 to 60 ºC, -4 to 140 ºF
• Assembly Options
  • NOSHOK offers multiple assembly options to meet your specific system requirements. Consult factory to discuss your customized solution.
• Case Type
  • Steel, Back Connection
• Connection Location
  • Back
• Connection Material
  • Brass
• Dial/Display Size
  • Aluminum, white background with black scale. UV resistant.
• Diaphragm Seals
  • NOSHOK offers a wide variety of standard & elevated pressure, and reduced pressure replaceable and non-replaceable diaphragm seals, designed to isolate and/or protect the pressure measuring instrument from corrosive, viscous, contaminated or very high temperature process media.
• Distribution Manifolds
  • NOSHOK's Distribution Manifolds connect multiple instruments to one diaphragm seal, eliminating multiple connections that lead to possible leak paths.
• Gauge Size
  • 2-1/2 in
• Installed Options and Accessories
  • Available Stainless Steel Case (SSC) Glass Lens (GL) (A steel or stainless cover ring must be additionally ordered when lenses other than plexiglass are utilized on all 200 Series models) Safety Glass Lens (SG) (A steel or stainless cover ring must be additionally ordered when lenses other than plexiglass are utilized on all 200 Series models) Plexiglass Lens (PL) Recalibrator Lens (RL) Red Set Pointer (SP) Maximum Indicating Pointer (MIP) Black Rear Flange (BLRF) Black Cover Ring (BCR) Stainless Steel Cover Ring (SSCR) Rubber Case Protectors (RCP) 10-32-UNF-2B (10-32) Orifice - Brass Threaded 0.3mm (BT3) - Standard Laser Marking (LM) Stainless Steel Tagging (ST) Certificates Certified Calibration (CC)
• Lens/Display Material
  • Acrylic
• Material
  • Black Painted Steel
• Media Temperature Range
  • -20 to 80 ºC, -4 to 176 ºF
• Metric Dials and Customized Special Dials
  • Dual scale metric dials in psi/bar, psi/kPa and psi/kg/cm 2 Other scales are available for specific sizes and ranges, such as single scale bar and kPa, refrigerant scales and altitude scales Customized special dials such as non-standard metric scale, tons of ram, lbs. of force, etc. are available in small quantities (as few as one piece) on some NOSHOK gauges Please consult the factory for availability.
• Movement
  • Brass and Nickel-Silver with Highly Polished Bearing Surfaces
• Pointer
  • Black Finished Aluminum
• Pressure Range
  • 0 to 10 inH 2 O
• Pressure Snubbers - Piston Type
  • Protect the instrument from the damaging effects of high temperature steam Recommended for use in all steam applications Available in 1/4" and 1/2" NPT sizes in welded steel, welded 316 Stainless Steel or seamless 316 Stainless Steel with ratings to 3800 psi at 850 ºF
• Series
  • 200
• Steam Syphons
  • Protect the instrument from the damaging effects of high temperature steam Recommended for use in all steam applications Available in 1/4" and 1/2" NPT sizes in welded steel, welded 316 Stainless Steel or seamless 316 Stainless Steel with ratings to 3800 psi at 850 ºF
• Stock
  • Yes
• Swivel Adapters
  • Temperature ratings: 15,000 psi at 200 ºF and 3,000 psi at 1,000 ºF Used with gauges and gauge valves to adjust the line of sight Rotates 360º to allow the connected instrument to be positioned in the desired direction The pressure connection is achieved with a tapered cone style compression fitting simply by tightening the swivel hex nut All 316 Stainless Steel construction Standard with 1/2" NPT male process - 1/2" NPT female instrument connections Also available with 1/4" NPT connections, same specifications apply Weight approximately 0.8 lb.
• Type
  • Low Pressure Gauge
• Uninstalled Options and Accessories
  • Certificate of Cleaning (COCL) Certificate of Conformance (COC)
• Warranty
  • 1 yr
• Working Pressure Limitations
  • Dynamic Pressure The working pressure should be limited to 60% of the dial range Static Pressure The working pressure, where no sharp fluctuations occur, should be limited to 90% of the dial range
