NOSHOK 25-100-160-psi/bar
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Accurate and reliable general purpose dry gauge with vacuum & compound ranges, and ABS or Steel case. Ideal for applications including hydraulics, pneumatics, medical, pumps, compressors, refrigeration controls and more.Multiple connection options are available including panel mount. A wide variety of pressure ranges, scale options, connections sizes, and options including flanges, case options, cover rings, lens materials, pointers, and orifices are also available.Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges.2-1/2" Acrylonitrile Butadiene Styrene (ABS) Case, Copper Alloy Internals, 160 psi/bar, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge
NOSHOK 25-100-160-psi/bar is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Accuracy
- 2.5 %
- Ambient Temperature Range
- -40 to 60 ºC, -40 to 140 ºF
- Assembly Options
- NOSHOK offers multiple assembly options to meet your specific system requirements. Consult factory to discuss your customized solution.
- Case Type
- Acrylonitrile Butadiene Styrene (ABS), Bottom Connection
- Connection Location
- Bottom
- Connection Material
- Brass
- Connection Size
- 1/4 in
- Dial/Display Size
- White background with black primary scale & red secondary scale. UV resistant.
- Diaphragm Seals
- NOSHOK offers a wide variety of standard & elevated pressure, and reduced pressure replaceable and non-replaceable diaphragm seals, designed to isolate and/or protect the pressure measuring instrument from corrosive, viscous, contaminated or very high temperature process media.
- Distribution Manifolds
- NOSHOK's Distribution Manifolds connect multiple instruments to one diaphragm seal, eliminating multiple connections that lead to possible leak paths.
- Gauge Size
- 2-1/2 in
- Installed Options and Accessories
- Available Red Set Pointer (SP) 10-32-UNF-2B (10-32) Orifice - Brass Press Fit Sintered, 20 Micron (CPO) Orifice - Brass Press Fit 0.1 mm (BP1) Orifice - Brass Press Fit 0.3 mm (BP3) - Standard Orifice - Brass Press Fit 0.8 mm (BP8) Laser Marking (LM) Stainless Steel Tagging (ST) Certificates Certified Calibration (CC) Cleaning for Oxygen Service (O 2 ), Up to 1,000 psi Cleaning for Oxygen Service (O 2 ), 1,500 psi and up Consult Factory Black Steel Case (BSC) Chrome Case (CRC) Stainless Steel Case (SSC) Silicone Dampened Movement (SDM) Glass Lens (GL) (A Steel, Stainless or Chrome Case & Cover Ring must be additionally ordered when Lenses other than acrylic are utilized on all 100 Series Models) Chrome Front Flange (SCFF) Steel Case Black Front Flange (SBFF) Steel Case Black Cover Ring (BCR) Stainless Steel Cover Ring (SSCR) Chrome Cover Ring (CCR)
- Lens/Display Material
- Acrylic
- Material
- Acrylonitrile Butadiene Styrene (ABS)
- Measuring Element
- Copper Alloy Bourdon Tube
- Media Temperature Range
- -20 to 60 ºC, -4 to 140 ºF
- Movement
- Brass & nylon, or all-brass with highly polished bearing surfaces
- Pointer
- Molded Plastic
- Pressure Range
- 0 to 160 psi
- Scale Option
- psi/bar Dual Scale
- Series
- 100
- Steam Syphons
- Protect the instrument from the damaging effects of high temperature steam Recommended for use in all steam applications Available in 1/4" and 1/2" NPT sizes in welded steel, welded 316 Stainless Steel or seamless 316 Stainless Steel with ratings to 3,800 psi at 850 ºF
- Stock
- Yes
- Swivel Adapters
- Temperature ratings: 15,000 psi at 200 ºF and 3,000 psi at 1,000 ºF Used with gauges and gauge valves to adjust the line of sight Rotates 360º to allow the connected instrument to be positioned in the desired direction The pressure connection is achieved with a tapered cone style compression fitting simply by tightening the swivel hex nut All 316 Stainless Steel construction Standard with 1/2" NPT male process - 1/2" NPT female instrument connections Also available with 1/4" NPT connections, same specifications apply Weight approximately 0.8 lb.
- Type
- Dry Pressure Gauge
- Uninstalled Options and Accessories
- Certificate of Cleaning (COCL) Certificate of Conformance (COC)
- Warranty
- 1 yr
