Molex 1053081206
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
Next Day Delivery
Based In The USA
Description
Nano-Fit Receptacle Housing, TPA Capable, 2.50mm Pitch, Dual Row, 6 Circuits, Black, Glow-Wire Capable
Molex 1053081206 is now available new, surplus, and used from Williams Automation.
If you need a specific firmware or series relating to this item, please call or email us with your request.
We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you require one.
Please note we offer UPS Next Day Air shipping for all orders. Please be sure to select next day shipping at checkout, and we will provide same-day shipment.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Agency Certification
- CSA
- LR19980
- UL
- E29179
Electrical
- Current - Maximum per Contact
- 6.5A
Physical
- Circuits (maximum)
- 6
- Color - Resin
- Black
- Flammability
- 94V-0
- Gender
- Receptacle
- Glow-Wire Capable
- Yes
- Keying to Mating Part
- Yes
- Lock to Mating Part
- Yes
- Material - Resin
- Nylon
- Net Weight
- 0.610/g
- Number of Rows
- 2
- Packaging Type
- Bag
- Panel Mount
- No
- Pitch - Mating Interface
- 2.50mm
- Pitch - Termination Interface
- 2.50mm
- Polarized to Mating Part
- Yes
- Temperature Range - Operating
- -40° to +105°C, -40° to +115°C
Product Environmental Compliance
- EU ELV
- Not Relevant
- EU RoHS
- Compliant
- Low-Halogen Status
- Low-Halogen
- REACH SVHC
- Not Contained Per -D(2020)9139-DC (19 Jan 2021)
Reference - Drawing Numbers
- Application Specification
- AS-105300-100-001
- Packaging Specification
- PK-105308-100-000
- Product Specification
- 1053001000-PS-CH-000, 1053001000-PS-ES-000, 1053001000-PS-JP-000, 1053001000-PS-SK-000, PS-105300-100-001
- Sales Drawing
- SD-105308-100-000
- Test Summary
- 1053000000-TS-000, 1053001000-TS-000
