Molex 1042345117
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
0.50mm Pitch Easy-On FFC Slim Connector, Right-Angle, Surface Mount, Double Bottom Contacts, 1.50mm Height, 51 Circuits
Molex 1042345117 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Electrical
- Current - Maximum per Contact
- 0.5A
- Voltage - Maximum
- 50V AC (RMS)/DC
General
- Category
- FFC/FPC Connectors
- Comments
- Black Actuator, Black Actuator
- Overview
- FFC-FPC (SMT)
- Product Name
- Easy-On
- Series
- 104234
- Status
- Active
- UPC
- 889056044837
Physical
- Actuator Type
- Flip
- Circuits (Loaded)
- 51
- Circuits (maximum)
- 51
- Color - Resin
- Natural
- Contact Position
- Bottom
- Durability (mating cycles max)
- 20
- Mated Height
- 1.50mm
- Material - Metal
- Phosphor Bronze
- Material - Plating Mating
- Gold over Nickel
- Material - Plating Termination
- Gold over Nickel
- Material - Resin
- Liquid Crystal Polymer
- Net Weight
- 0.378/g
- Number of Rows
- 1
- Orientation
- Right Angle
- Packaging Type
- Embossed Tape on Reel
- PCB Mounting
- Surface Mount
- PCB Retention
- Yes
- Pitch - Mating Interface
- 0.50mm
- Plating min - Mating
- 0.102µm
- Plating min - Termination
- 0.051µm
- Polarized to PCB
- Yes
- Stackable
- No
- Temperature Range - Operating
- -20° to +85°C
- Wire/Cable Type
- FFC only
Product Environmental Compliance
- EU ELV
- Not Relevant
- EU RoHS
- Compliant
- Low-Halogen Status
- Low-Halogen
- REACH SVHC
- Not Contained Per -ED/88/2018 (15 January 2019)
Reference - Drawing Numbers
- Packaging Specification
- PK-104234-001-001, SPK-104234-001-001
- Product Specification
- PS-104234-001-001
- Sales Drawing
- SD-104234-001
