Mersen 83120167
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
STP T1+2 5 PV is the PHOTOVOLTAIC range of combined Type 1+2/Class I+II devices intended for discharging lightning currents (10/350 μs) and protecting against induced voltage surges (8/20 μs), in accordance with EN 50539-11 and IEC 61643-31 standards. These products provide advanced protection to photovoltaic systems by utilizing Mersen’s optimized dynamic thermal disconnection system, which does not require additional overcurrent protection (back-up fuse) due to its high short-circuit withstand rating. The devices are suitable for all PV applications large-scale and rooftop. The series includes specific multipole products for multiple MPPT inverters.SPD T1+2,5kA,Ucpv 1060V,YPV,3P,Plug
Mersen 83120167 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Ac Or Dc
- DC
- Country Of Origin
- ES
- Housing Material
- PA6 CT1; V-0
- Iec Spd Type
- Type 1+2 IEC 61643-31, Type 1+2 EN 50539-11
- Iscpv
- 10 kA (EN 50539-11), no back-up fuse required
- Lightning Impulse Current 10 350 Iimp
- 5 kA
- Lightning impulse current (10/350 us)
- 5kA
- Max Discharge Current Imax 8 20
- 40kA
- Maximum discharge current (8/20μs)
- 40 kA
- Max Operating Temp
- 85 °C
- Min Operating Temp
- -40 °C
- Nominal Discharge Current
- 20kA
- Nominal discharge current (8/20μs)
- 15 kA, 20 kA
- Nominal Operating Volt Rating Un
- 1000 V
- Number Of Poles
- 3-Pole
- Product Brand
- Surge-Trap®
- Product Line
- Surge-Trap® Pluggable STPT1+2 Series - 5kA PV
- Protection Modes
- PV
- Replacement Plug L-N
- SP12-5K1000V-PV
- Response Time
- 25 ns
- System Configuration
- PV
- Torque Rating
- 35.4 lb-in
- Ucpv
- 1060 V
- 1060 Vdc, 1500 Vdc
- Up At In L-L
- ≤4.0 kV
- Up At In L-Pe
- ≤4 kV
- Wire Type
- Rigid: 6…35mm²
