Description
STM T1 50 is the most robust series of single pole Type 1/Class I lightning current arresters, able to discharge energy (current) from a direct lightning strike (10/350µs) on an external lightning protection system (LPS) or overhead supplies, in accordance with EN/IEC 61643-11. Suitable as the first step of protection in incoming power supply panels and areas with high exposure to lightning strikes, fitted with an external lightning protection system.SPD Type 1, 100kA, Uc255V, N, 1 Pole, 2 Modules, Monobloc
Mersen 83010102 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Ac Or Dc
- AC
- Back-up fuse
- 500 A gG
- Country Of Origin
- ES
- Follow current quenching capacity (Ifi)
- 50kA
- Following Current Ifi
- 0,1 kA
- Housing Material
- PC+GF; V-0
- Iec Spd Type
- Type 1 / Class I
- Lightning Impulse Current 10 350 Iimp
- 100 kA
- Lightning impulse current (10/350μs)
- 50kA
- Max Back-Up Fuse
- 500 A gG
- Max Operating Temp
- 80 °C
- Min Operating Temp
- -40 °C
- Nominal Discharge Current
- 100kA
- Nominal Operating Volt Rating Un
- Neutral
- Number Of Poles
- 1-Pole
- Product Brand
- Surge-Trap®
- Product Line
- Surge-Trap® Monobloc STMT1 Series - 50kA
- Protection Modes
- TT
- System Configuration
- TT
- Torque Rating
- 35.4 lb-in
- Uc N-Pe
- 255 V
- Un(L-N/L-L)
- 120/208V, 230/400V, 277/480V, 400/690V
- Up At In N-Pe
- ≤2.0 kV
- Wire Type
- Rigid: 16…35mm² / Stranded: 16…25mm²
