Leviton 42277-DY3
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
277/480V 220/380V 3-Phase WYE, 240V 480V 3-Phase Delta, Surge Panel, Enhanced Noise Filtering, NEMA 3R Enclosure, UL 1449 4th Edition Type 2Type 2 3-Phase Surge Panel with Enhanced Noise Filtering
Leviton 42277-DY3 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Electrical Specifications
- EMI/RFI Noise Rejection
- (-30 to -40 @ 10K - 10MHz)
- Frequency
- 50/60Hz
- Recommended Circuit Breaker Rating
- 30A, 277/480V
- Surge Technology
- 40mm MOV Design
- Voltage Configuration
- 220/380 V or 277/480 V, 3-Phase WYE; 240 V or 480 V, 3-Phase Delta
Environmental Specifications
- Enclosure
- Type 3R
- Flammability
- Rated V-2 per UL 94
- Operating Temperature
- -10°C to 60°C
- Relative Humidity
- 5% to 95% non-condensing
- Storage Temperature Range
- -20C to 85C
Material Specifications
- Outer Enclosure
- Powder Coated Steel
Mechanical Specifications
- Connection Type
- Parallel - Hardwired via 12 AWG Wire
- Remote Monitoring
- Dry Contact Leads-N.O./N.C. Form C Rated at 7Amps @ 240VAC or 30 VDC
- Surge Counter
- No
Performance Data
- Maximum Surge Current, Per Mode (Per Phase)
- 80kA (160kA)
- MCOV L-G
- 640
- MCOV L-L
- 552
- MCOV L-N
- 320
- MCOV N-G
- 320
- Nominal Discharge Current Rating
- 3kA
- Short Circuit Current Rating
- 100kA
- VPR L-G
- 2000
- VPR L-L
- 1800
- VPR L-N
- 1200
- VPR N-G
- 1200
Product Features
- Diagnostics
- LED
- MCOV
- 320V AC
- Noise Rejection
- -30 to -40 dB at 10kHz-10MHz
- Replaceable Modules
- No
- UL1449 Impluse 6kV/500A L-N/N-G/L-L
- 900/800/1500
Specifications
- Country of Origin
- Mexico
Standards and Certifications
- ANSI/IEEE Category A, B & C
- C-62.41 & 62.45
- UL 1449 4th Edition
- cULus Listed Type 2
Warranty
- Warranty
- 5-Year Limited
