Killark XS-42C

Certifications

• EU RoHS Indicator
  • Contact Manufacturer

Specifications

• Action
  • DP
• Actuator
  • Lever
• Ambient Temp. Range
  • UL: -25 to 40 ºC, CSA: -50 to 40 ºC, IEC: -20 to 40 °C
• Amperage Rating
  • 20 A
• Application
  • Used where making, breaking, or changing connections in an electric circuit is required.
• ARRA Compliant
  • Contact Manufacturer
• Back Box Type
  • SWB
• Base Unit of Measure
  • EA
• Buy American Compliant
  • Contact Manufacturer
• Carton - SCC-14 Next Lower Level Sub Pack
  • 00783936930466
• Class Code
  • D25
• Color
  • Gray
• Country of Origin
  • CN
• CSA File Number
  • LR11712
• Depth
  • 4-1/4
• Description - Invoice
  • CLI 20A 2P 1/2" FEED-THRU (CS)
• Each - Width
  • 3.000 in
• Freight Class Code
  • 06316009
• Frequency Rating
  • 50/60 Hz
• Gross Weight with Packaging
  • 2.4
• Harmonization Code
  • 8536509040
• Hazardous Rating(s)
  • Class I, Divisions 1 & 2, Groups C, D;Class I, Zones 1 & 2, Groups IIB, IIA;Class II, Divisions 1 & 2, Groups E, F, G;Class III, Divisions 1 & 2
• Image Actual Or Representative
  • R
• Master Pack Description
  • Each
• MSDS Flag
  • No
• Number of Poles
  • 2
• Number Of Poles
  • 2
• Order Multiple
  • 1 EA
• Returnable Indicator
  • Yes
• Series
  • XS
• Special Features
  • Killark XCS SERIES TUMBLER SWITCH Control Stations provide control means in hazardous location areas turning ON and OFF Motors, Fans, Lights etc.Utilized in Class 1 Division 1 & 2, Class 1 Zone 1 & 2 areas for indoor use are a Non-Factory Sealed unit requiring the need for a conduit seal fitting. UL Listed and CSA Certified.
• Sub Class Code
  • D25D250
• Type
  • Aluminum Tumbler Switch Box And Cover
• UL File Number
  • E53360
• Width
  • 3.000 in
