ILSCO PICS-70
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Aluminum Insulated Service Entrance Sleeve, Dual Rated, Main Conductor Range 1-2, Tap Range 6 Sol - 8, Red Color Code, Die Index ND-BG
ILSCO PICS-70 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Additional Class Attributes
- Barrel Marking
- Ink
- Barrel Type
- Standard
- Flared End
- No
- ILSCOs Die Index Number
- ND-BG
Additional Technical Specifications
- Conductor Type
- Stranded, Solid
Color
- Color
- Black
- Color Code
- Red
- Color Code Secondary
- Green
Conductor Ranges
- Conductor Range ACSR (Secondary, tap, load)
- 2 ACSR
- Conductor Range AL Solid (Primary, run, main, line)
- 6 Sol - 8 Sol
- Conductor Range AL Solid (Secondary, tap, load)
- 6 Sol - 8 Sol
- Conductor Range AL Stranded (Primary, run, main, line)
- 1 Str - 2 Str
- Conductor Range AL Stranded (Secondary, tap, load)
- 6 Str - 8 Str
- Conductor Range CU Solid (Primary, run, main, line)
- 1 Sol
- Conductor Range CU Solid (Secondary, tap, load)
- 6 Sol - 8 Sol
- Conductor Range CU Stranded (Primary, run, main, line)
- 1 Str - 2 Str
- Conductor Range CU Stranded (Secondary, tap, load)
- 6 Str - 8 Str
Dimensions
- Height BX (IN)
- 3.75
- Height (mm)
- 18.288
- Length (mm)
- 71.374
- Weight BX (LB)
- 2.813
- Width BX (IN)
- 6.375
- Width (mm)
- 18.288
General
- Bag Quantity
- 1
- Carton Quantity Description
- STD PACK QTY 50
- Direct Burial
- No
- Dual Rated
- Yes
- NEMA Code
- 0-000-1
- UPC Code
- 78366923292
Material and Finish
- Conductor Material
- Aluminum, Copper
- Insulation
- Nylon
- Material
- Aluminum
Specifications
- Height
- 0.72 in | 18.288 mm
- Length
- 2.81 in | 71.374 mm
- Weight
- 0.0436592936497615 lbs
- Width
- 0.72 in | 18.288 mm
Testing Standards
- ANSI Specification
- ANSI C119.4
- Prop65 Compliance
- This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- RUS Listed
- Yes
