ILSCO CLNU-650-9
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Surecrimp Copper Compression Lug, Copper material, Tin plated connector,Long barrel, standard tang, 1 mounting hole(s), UL 486A/B Listed, C22.2 No. 65-03, 180° connecting angle, Copper Primary Conductor 650 kcmil, no sight window, Square tang end, flex conductor range 500 G,H,I, K,M 535.3 DLO, rated for 35 kV, die color code Pink, primary color Silver, die index I-99,Surecrimp Copper Compression Lug, Conductor Size 650, No Hole, 90° Bent Tang, Long Barrel, No Sight Window, Tin Plated, UL, CSA
ILSCO CLNU-650-9 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Bag Quantity
- 1
- Barrel Length (IN)
- 2.687
- Barrel Length (mm)
- 68.2498
- Barrel Marking
- Ink
- Barrel Type
- Long
- Color
- Silver
- Conductor Material
- Copper
- Conductor Range CU Stranded (Primary, run, main, line)
- 650 kcmil
- Conductor Size CU (Primary, run, main, line)
- 650 kcmil
- Conductor Type
- Stranded,Flex
- Connecting angle
- 180°
- Connection
- Compression
- Connector Finish
- Tin
- Contains DE-OX
- FALSE
- CrossSell
- ILD-99, DE-OX-8OZ, TB-6DF1000-P
- CSA File Number
- LR-29601
- CSA Standard
- C22.2 No. 65-03
- Die Color Code
- Pink
- Dimension G (mm)
- 0
- Direct Burial
- FALSE
- Dual Rated
- FALSE
- Expanded Conductor Range
- 650 kcmil - 350 kcmil
- Expanded Conductor Size
- 650 kcmil,600 kcmil,550 kcmil,500 kcmil,450 kcmil,400 kcmil,350 kcmil
- Flared End
- FALSE
- Flex Conductor Range
- 500 G,H,I, K,M 535.3 DLO
- Flex Conductor Size (Class DLO)
- 535.3 DLO
- Flex Conductor Size (Class G)
- 500 G
- Flex Conductor Size (Class H)
- 500 H
- Flex Conductor Size (Class I)
- 500 I
- Flex Conductor Size (Class K)
- 500 K
- Flex Conductor Size (Class M)
- 500 M
- Height (IN)
- 4.378
- Height (mm)
- 111.2012
- ILSCOs Die Catalog Number
- ILD-99
- Inside Diameter (IN)
- 0.958
- Inside Diameter (mm)
- 24.3332
- Length (IN)
- 4.021
- Length (mm)
- 102.1334
- Material
- Copper
- Mounting Hole Diameter (mm)
- 0
- Mounting Hole Spacing (mm)
- 0
- Narrow Tang
- FALSE
- NEBS Rating
- Level 3
- Number of Mounting Holes
- 1
- Outside Diameter (IN)
- 1.217
- Outside Diameter (mm)
- 30.9118
- Prop65 Compliance
- This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- Sight Window
- FALSE
- Slotted
- FALSE
- Strip Length (mm)
- 69.8246
- Tang End Shape
- Square
- Tang Length (IN)
- 3
- Tang Length (mm)
- 76.2
- Tang Thickness (IN)
- 0.259
- Tang Thickness (mm)
- 6.5786
- Tang Width (IN)
- 1.764
- Tang Width (mm)
- 44.8056
- Temperature Rating
- 90°C
- UL Control Number
- 453G
- UL / CULUS Specification
- UL 486A/B Listed
- UL File Number
- E6207
- Undrilled
- TRUE
- UNSPSC Code
- 39121448
- UPC Code
- 78366968510
- Voltage Rating
- 35 kV
- Weight (LB)
- 0.995416809
- Width (IN)
- 1.764
- Width (mm)
- 44.8056
