Description
Straight Blade Devices, Receptacles, Style Line Decorator, SNAPConnect, Hospital Grade, Tamper Resistant, Split Circuit, 20A 125V, 2-Pole 3- Wire Grounding, 5-20R, Nylon, White, USAStraight Blade Devices, Receptacles, Style Line Decorator, SNAPConnect, Hospital Grade, Tamper Resistant, Split Circuit, 20A 125V, 2-Pole 3- Wire Grounding, 5-20R, Nylon, White, USA
Hubbell Wiring Device-Kellems SNAP2182WSCTRA is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- EU RoHS Indicator
- Contact Manufacturer
Specifications
- Amperage Rating
- 20 A
- Application
- Hospital Grade
- Base Unit of Measure
- EA
- BOX SIZE
- 3.548x9.858x4.298 (in)
- Carton - Gross Weight per Pack
- 2.300 lb.
- Carton - Number of Sub Packs
- 10
- Carton - Pack Description
- Carton
- Carton - SCC-14 Next Lower Level Sub Pack
- 00783585552521
- Carton - Total Units
- 10
- Case Weight
- 20.000 lb.
- Class Code
- A04
- Color
- White
- Connectivity
- Connectorized
- Country of Origin
- MX
- Current / Amperage Rating
- 20 A
- Current Rating
- 20 A
- Description - Invoice
- SNAPCONNECT DECO HG 20A/125V SC TR WH
- Dielectric Strength
- Withstands 2,000V minimum
- Dimensions
- 3.28 in x 1.64 in x 1.1 in
- Display Size
- Standard Sized Product
- Each - Width
- 1.910 in
- Environmental Conditions
- Indoor Dry Unless Protected By Additional Means
- Freight Class Code
- 06168002
- Harmonization Code
- 8536698000
- Height
- 1.1 in
- Horsepower - Maximum
- 1
- Image Actual Or Representative
- A
- Industry Standard(s)
- Certified to CSA, C22.2, No. 42 File 285;Fed. Spec. W-C-596;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186
- Length
- 3.28 in
- Material
- Nylon
- MSDS Flag
- No
- Nema Rating
- 5-20R
- NEMA Rating
- 5-20R
- Number Of Conductors
- 3-Wire Grounding
- Number of Poles
- 2-Pole
- Number Of Poles
- 2-Pole
- Number of Wires
- 3-Wire
- Number Of Wires
- 3-Wire
- Operating Temperature
- Maximum continuous 75°C and minimum -40°C without Impact
- Performance
- Electrical: Current Interrupting- Certified for current interrupting at full rated current;Electrical: Dielectric Voltage- Withstands 2,000V minimum;Mechanical: Product Identification Ratings are a permanent part of the device;Environmental: Flammability- UL 94V-2;Environmental: Operating Temperature- Maximum continuous 75°C;minimum -40°C (w/o impact)
- Phase
- Single Phase
- Replaced Catalog Number
- SNAP2182WSCTR
- Series
- Hospital Grade
- Size
- 3.28 in x 1.64 in x 1.1 in
- Special Features
- Quick Connect- SNAPConnect, Tamper-Resistant, Split Circuit, USA Product
- Standard
- Certified to CSA, C22.2, No. 42 File 285;Fed. Spec. W-C-596;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186
- Style
- Style Line Decorator
- Sub Class Code
- A04A040
- Type
- Tamper-Resistant, Split Circuit
- Voltage Rating
- 125 V
- Voltage Rating Description
- 125 V
- Wattage
- 2500 W
- Weight
- 0.2 lb.
- Width
- 1.910 in
- Wire Size
- #12 AWG
