Hubbell IG5262ISA
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
IG TVSS Duplex Receptacle with Light and Alarm, 15A 125V, 5-15R, GrayIG TVSS Duplex Receptacle with Light and Alarm, 15A 125V, 5-15R, Gray
Hubbell Wiring Device-Kellems IG5262ISA is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- EU RoHS Indicator
- No
Specifications
- Amperage Rating
- 15 A
- Application
- Decorator Duplex with Light and Alarm
- Base Unit of Measure
- EA
- BOX SIZE
- 4.100x11.300x4.500 (in)
- Carton - Gross Weight per Pack
- 3.1 lb.
- Carton - Number of Sub Packs
- 10
- Carton - Pack Description
- Carton
- Carton - SCC-14 Next Lower Level Sub Pack
- 783585060613
- Carton - Total Units
- 10 EA
- Case Weight
- 15.000 lb.
- Class Code
- A44
- Color
- Ivory
- Connectivity
- Terminal Screws
- Country of Origin
- CN
- Current / Amperage Rating
- 15 A
- Current Rating
- 15 A
- Description - Invoice
- DUP SPD RCPT, IG, 15A 125V, 5-15R, IV
- Display Size
- Standard
- Each - Pack Description
- Each
- Each - Width
- 2.200 in
- Environmental Conditions
- Indoor Dry Unless Protected By Additional Means
- Freight Class Code
- 06168002
- Frequency Rating
- 60 Hz
- Harmonization Code
- 8537109170
- Image Actual Or Representative
- A
- Indicator(s) Type
- LED and Audible Alarm
- Industry Standard(s)
- CSA Certified to Specification C22.2 No. 42;Listed to UL Standards 498;UL Listed File E2186
- Lowest Level UOM
- Each
- Material
- Composite
- Material - Mounting Hardware
- Mounting Screws
- MSDS Flag
- No
- Nema Rating
- 5-15R
- Operating Temperature
- 32 Deg F to 140 Deg F (0 Deg C to 60 Deg C)
- Outlet
- Straight Blade
- Performance
- Electrical - Protection Modes - Normal and Common Modes;Electrical - Response Time - Approximately 5 ns;Electrical - Transient Suppression - Peak Energy (10 X 100 µs), Peak Current (8 X 20 µs);Electrical - Voltage - 120V AC + 10% - 15%;Environmental - Flammability - UL 94V-2;Environmental - Operating Temperature - 32°F to 140°F (0°C to 60°C)
- Phase
- Single Phase
- Replaced Catalog Number
- IG5252IS;IG5262IS
- Response Time
- 5
- Series
- Specification Grade
- Special Features
- Isolated Ground
- Standard
- CSA Certified to Specification C22.2 No. 42;Listed to UL Standards 498;UL Listed File E2186
- Style
- Isolated Ground
- Sub Class Code
- A44A420
- Type
- Duplex
- Voltage Rating
- 125 V
- Voltage Rating Description
- 125 V
- Width
- 2.200 in
