Hubbell HBL420HRS
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Straight Blade Devices, 4-Plex Receptacle, Commercial Grade, Surge Protected, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, RedStraight Blade Devices, 4-Plex Receptacle, Commercial Grade, Surge Protected, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, Red
Hubbell Wiring Device-Kellems HBL420HRS is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- EU RoHS Indicator
- No
Specifications
- Amperage Rating
- 20 A
- Application
- 4-Plex Hospital Grade
- Base Unit of Measure
- EA
- BOX SIZE
- 5.125x6.245x6.245 (in)
- Carton - Gross Weight per Pack
- 2.450 lb.
- Carton - Number of Sub Packs
- 10
- Carton - Pack Description
- Carton
- Carton - SCC-14 Next Lower Level Sub Pack
- 783585252353
- Carton - Total Units
- 5 EA
- Case - Total Units
- 30 EA
- Case Weight
- 7.500 lb.
- Class Code
- A44
- Color
- Red
- Connectivity
- Back Wired Screw Terminals
- Country of Origin
- PR
- Current / Amperage Rating
- 20 A
- Current Rating
- 20 A
- Description - Invoice
- 4-PLEX HG SPD RCPT, 20A 125V, 5-20R, RD
- Display Size
- Standard Sized Product
- Each - Pack Description
- Each
- Each - Width
- 4.420 in
- Environmental Conditions
- Indoor Dry Unless Protected By Additional Means
- Freight Class Code
- 06168002
- Harmonization Code
- 8536308000
- Image Actual Or Representative
- A
- Industry Standard(s)
- Certified to CSA 22.2, No. 42 File 285;Listed to UL Standard 498 File E2186
- Lowest Level UOM
- Each
- Material
- Polycarbonate
- Material - Mounting Hardware
- Screw Mounting
- MSDS Flag
- No
- Nema Rating
- 5-20R
- NEMA Rating
- 5-20R
- Number of Poles
- 2-Pole
- Number Of Poles
- 2-Pole
- Number of Wires
- 3-Wire Grounding
- Number Of Wires
- 3-Wire Grounding
- Performance
- Electrical - Frequency - 60Hz;Electrical - Protection Modes - Normal and Common Modes;Electrical - Response Time - Approximately 5 ns;Electrical - Transient Suppression - Peak Energy (10 X 100 µs), Peak Current (8 X 20 µs);Electrical - Voltage - 20V AC + 10% - 15%;Environmental - Flammability - UL 94V-2;Environmental - Operating Temperature - -40°F to 140°F (-40°C to 60°C)
- Phase
- Single Phase
- Series
- Hospital Grade
- Special Features
- 4 Receptacles in one, Surge Protective Device
- Standard
- Certified to CSA 22.2, No. 42 File 285;Listed to UL Standard 498 File E2186
- Sub Class Code
- A44A420
- Type
- 4-Plex
- Voltage Rating
- 125 V
- Voltage Rating Description
- 125 V
- Wattage
- 2500
- Width
- 4.420 in
- Wire Size
- #14 AWG to #12 AWG
