Honeywell MLH500PSCDJ1240
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Honeywell MLH500PSCDJ1240 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Application
- Single point
- Burst Pressure Rating
- 10X Working pressure range
- Connection Material
- Stainless steel 304L and Haynes 214 alloy
- Connection Size
- 4-Jan in
- Connection Type
- 2-wire ; SAE female Schrader
- Display
- No
- Housing Material
- Black plastic- A model AS-4133 HS-PPA
- Includes
- Cable (3 meter)
- Maximum Operating Ambient Temperature
- 257 °F ; 125 °C
- Maximum Shipping & Storage Temperature
- 257 °F ; 125 °C
- Measured Pressure Accuracy
- 0.25% of full scale span
- Minimum Operating Ambient Temperature
- -40 °F ; -40 °C
- Minimum Shipping & Storage Temperature
- -40 °F ; -40 °C
- Mounting Style
- Gauge Mount
- Output Signal Range
- 4 to 20 mA
- Overall Width
- 119.7 in ; 3,040 mm
- Pressure Sensor Range
- 0 - 500
- Proof Pressure Rating
- 3X Working pressure range
- Regulatory Approvals
- CE Approved
- Supply Voltage
- 9.5 to 30 V DC
