HellermannTyton 596-23320
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This self-laminating label consists of a printable area plus a lamination function for protection of print text against humidity, dirt, debris and mechanical abrasion. It is ideally suited for wire and cable marking in both high temperature and outside environments, particular used in industry as well as military technology.Self-laminating labels, thermal transfer
HellermannTyton 596-23320 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Base Data
- Application Tool
- TT431, TT431-BV, TT4030
- Colour
- White (WH), Transparent (CL)
- Colour Marking Field
- White (WH)
- Fixation Method
- Pasting / Stick
- Mounting method
- Pasting / Stick
- Package Quantity per
- pcs.
- Pack Cont.
- 5000pcs.
- PART DESCRIPTION
- TAG23TD5-323-WHCL-323-CL/WH
- Product Family
- Material 323 (White/yellow-Clear) high temperature
- Product Group
- Self-laminating labels, thermal transfer
- Short Description
- Self-laminating labels, thermal transfer 19.05x44.50 mm white-transparent
- Variant
- Roller form
- With label space
- Yes
Logistics and Packaging
- EAN / GTIN
- 4031026213637
- Labels per Row
- 5pcs.
- Packaging 1 - Height (m)
- 0.15m
- Packaging 1 - Length (m)
- 0.165m
- Packaging 1 - Qty
- 5000
- Packaging 1 - Type
- bag
- Packaging 1 - Volume (m³)
- 0.00265m³
- Packaging 1 - Weight (kg)
- 0.815kg
- Packaging 1 - Width (m)
- 0.107m
- Packaging 3 - Height (m)
- 0.24m
- Packaging 3 - Length (m)
- 0.55m
- Packaging 3 - Qty
- 60000
- Packaging 3 - Type
- carton
- Packaging 3 - Volume (m³)
- 0.0515m³
- Packaging 3 - Weight (kg)
- 10.28kg
- Packaging 3 - Width (m)
- 0.39m
- Weight
- 0.815kg
Material and Specifications
- Adhesive
- Acrylic
- Chem. Material Properties
- Excellent resistance against water, UV radiation, weather influence and solvents based on petroleum.
- Curing Temperature
- from +10 °C
- ELV compliant (Article 4 - 2)
- YES
- Halogenfree
- No
- Hazardous good
- No
- Material
- Type 323, Polyvinylidene Fluoride (PVDF)
- Mech. material properties
- Permanent adhesive, extremely scratch resistant
- Operating Temperature - °C
- -40 °C to +140 °C, intermittent +160 °C
- Recommended Ribbon Type
- TT932DOUT
More Information
- ETIM 6.0
- EC001530
- ETIM 7.0 Key
- EC001530
Product Dimensions
- Bundle ∅ max.
- 10.0mm
- Bundle ∅ min.
- 4.5mm
- Height (H)
- 12.70mm
- Height (H2)
- 44.50mm
- H printable
- 12.70mm
- HR
- 19.05mm
- Print Method
- Thermal transfer or laser beam
- Thickness of Foil
- 25µm
- Thickness (T)
- 25.0µm
- VR
- 50.80mm
- Width of Liner (WL)
- 101.6mm
- Width (W)
- 19.05mm
