HellermannTyton 554-51801
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TLFX is a halogen free European rail approved 2:1 heat shrink marker material supplied as a continuous tube and printable on both sides. Special material properties show low smoke propagation, density and toxicity. The tubing has been especially prepared so that print performance is excellent at all times. HellermannTyton's printer range allow users to create a high quality print. In addition it is possible to either perforate the tubing at pre-determined lengths or fully sever the markers.Shrinkable markers "Continuous Tube", thermal transfer
HellermannTyton 554-51801 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Base Data
- Application Tool
- TT431, TT431-BV, TT4030, TrakMark DS
- Colour
- Yellow (YE)
- Package Quantity per
- pack
- Pack Cont.
- 13m
- PART DESCRIPTION
- TLFX381YE-PO-X-YE
- Printable (Yes/No)
- Yes
- Product Family
- TLFX – 2:1 Rail Limited Fire Hazard
- Product Group
- Shrinkable markers "Continuous Tube", thermal transfer
- Short Description
- continuous heat shrink tubing TLFX 2:1 38.1/19.0 PO-X Yellow 13m/BOX = 1 reel
- Shrink Ratio
- 2:1
- Variant
- Thin-Wall
- With inner glue (Yes/No)
- No
Logistics and Packaging
- EAN / GTIN
- 4031026443409
- Packaging 1 - Height (m)
- 0.168m
- Packaging 1 - Length (m)
- 0.168m
- Packaging 1 - Qty
- 1
- Packaging 1 - Type
- carton
- Packaging 1 - Volume (m³)
- 0.0031m³
- Packaging 1 - Weight (kg)
- 1.15kg
- Packaging 1 - Width (m)
- 0.11m
- Weight
- 1.04kg
Material and Specifications
- ELV compliant (Article 4 - 2)
- YES
- EN 45545-2 Results
- R22 HL2, R23 HL3
- Halogenfree
- Yes
- Hazardous good
- No
- Limited Fire Hazard
- Yes
- Material
- Polyolefin, cross-linked (PO-X)
- Min. Shrink Temperature - °C
- +100 °C
- Operating Temperature - °C
- -55 °C to +105 °C
- Oxygen Index
- 32.5%
- Recommended Ribbon Type
- TTDTHOUT
- Specifications
- BS-6853:1999, DIN 53438-3: 1984, DIN 5510-2, DIN EN 45545-2 (02/2016), EN ISO 11925-2: 2002, NF F 16-101
More Information
- ETIM 6.0
- EC000217
- ETIM 7.0 Key
- EC000217
Product Dimensions
- Length (L)
- 13.0m
- Longitudinal Change After Shrinkage
- -5 % max.
- Print Method
- Thermal transfer or laser beam
- Recov. ∅ d max.
- 19.0mm
- Supplied ∅ D min.
- 38.1mm
- Wall (WT)
- 0.70mm
