HellermannTyton 311-00959
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Typical applications of this translucent tubing are where high-temperature performance is required. Also very suitable for applications that ask for visual inspection of covered components, or if low friction surface is needed. TK20 is also used as oil stop for energy cables.
This thin walled, translucent heat shrink tubing is often used for chemical applications.Heat shrinkable tubing 2:1 - PVDF
This thin walled, translucent heat shrink tubing is often used for chemical applications.Heat shrinkable tubing 2:1 - PVDF
HellermannTyton 311-00959 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Base Data
- Application Tool
- H5002, H5004, E4500
- Behaviour at Heat Shock
- not dripping, not fluid, not cracking
- Behaviour At Low Temperature
- not cracking
- Colour
- Transparent (CL)
- Heat Aging Test
- 168h/175°C
- Heat Shock Test
- 4h/250°C
- Minimum Elongation At Heat Aging
- 200%
- Package Quantity per
- pcs.
- Pack Cont.
- 50pcs.
- PART DESCRIPTION
- TK20-9.5/4.8-PVDF-CL
- Printable (Yes/No)
- No
- Product Family
- TK20
- Product Group
- Heat shrinkable tubing 2:1 - PVDF
- Short Description
- Heat Shrinkable Tubing 2:1 PVDF transparent 9.5/4.8
- Shrink Ratio
- 2:1
- Size
- 3/8"
- Variant
- Thin-Wall
- With inner glue (Yes/No)
- No
Logistics and Packaging
- EAN / GTIN
- 4031026223803
- Packaging 1 - Height (m)
- 0.15m
- Packaging 1 - Length (m)
- 1.27m
- Packaging 1 - Qty
- 50
- Packaging 1 - Type
- bag
- Packaging 1 - Volume (m³)
- 0.02477m³
- Packaging 1 - Weight (kg)
- 0.550001kg
- Packaging 1 - Width (m)
- 0.13m
- Packaging 3 - Height (m)
- 0.105m
- Packaging 3 - Length (m)
- 1.3m
- Packaging 3 - Qty
- 250
- Packaging 3 - Type
- carton
- Packaging 3 - Volume (m³)
- 0.0143m³
- Packaging 3 - Weight (kg)
- 4.262205kg
- Packaging 3 - Width (m)
- 0.105m
- Weight
- 0.55kg
Material and Specifications
- Designation as per VG-Norm
- VG 95343 T05 F 007 M
- Dielectric Strength
- 43 kV/mm
- Elongation at break
- ≥350%
- ELV compliant (Article 4 - 2)
- YES
- Flammability
- UL 224 VW-1
- Halogenfree
- No
- Hazardous good
- No
- Insulation Class
- F (VDE 0530)
- Material
- Polyvinylidene Fluoride (PVDF)
- Min. Shrink Temperature - °C
- +170 °C
- Nato number
- D8527
- Operating Temperature - °C
- -55 °C to +175 °C
- Specifications
- ANSI/UL 224, ASNE 0718, SAE-AMS-DTL-23053/8, VG 95343-5:2006-06
- Tensile Strength
- 41MPa
- UL-File Number
- E198023
- UL OCD link
- YDTU2.E198023
- UL Recognized (US and Canada)
- Yes
- Volume Resistance
- 10¹⁵ Ω cm
- Water Absorption
- 0.2%
More Information
- ETIM 6.0
- EC000217
- ETIM 7.0 Key
- EC000217
Product Dimensions
- Length (L)
- 1.20m
- Longitudinal Change After Shrinkage
- +/-10 % max
- Recov. ∅ d max.
- 4.8mm
- Supplied ∅ D min.
- 9.5mm
- Tube Shape
- Oval
- Wall (WT)
- 0.30mm
