Harting 10360070001
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Connector sets, Crimp termination, Rated current: 10 A, Contacts: 7, Size: 3 A, Single locking lever, Top entry, 1x M20, Material: Zinc die-cast, Powder-coated, Degree of protection: IP67, with seal screw 09 20 000 9918Connector sets, Crimp termination, Rated current: 10 A, Contacts: 7, Size: 3 A, Single locking lever, Top entry, 1x M20
Harting 10360070001 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Commercial data
- Country of origin
- Germany
- eCl@ss
- 27440101 Rectangular connectors (set)
- European customs tariff number
- 85366990
- Net weight
- 123.74 g
- Packaging size
- 1
Identification
- Category
- Connector sets
- Element
- Complete set
- Series
- Han
- Series of hoods/housings
- Han
Material properties
- China RoHS
- 50
- Colour (hood/housing)
- RAL 5015 (sky blue)
- ELV status
- compliant with exemption
- Material flammability class acc. to UL 94
- V-0
- Material (hood/housing)
- Zinc die-cast
- Material (insert)
- Polycarbonate (PC)
- Material (locking)
- Stainless steel
- Material (seal)
- NBR
- REACH ANNEX XIV substances
- No
- REACH Annex XVII substances
- No
- REACH SVHC substances
- Lead
- RoHS
- compliant with exemption
- Surface (hood/housing)
- Powder-coated
Specifications and approvals
- Specifications
- EN 60664-1 || IEC 61984 || EN 60079-0 || EN 60079-11
Technical characteristics
- Degree of protection acc. to IEC 60529
- IP67 with seal screw 09 20 000 9918
- Insulation resistance
- >10
- Limiting temperature
- -20 ... +40 °C
- Mating cycles
- ≥ 500
- Rated current
- 10 A
- Rated voltage
- 90 V
Version
- Cable entry
- 1x M20
- Details
- Please order crimp contacts separately.
- Field of application
- Connectors for explosion hazardous environments
- Locking type
- Single locking lever
- Number of contacts
- 7
- PE contact
- Yes
- Size
- 3 A
- Termination method
- Crimp termination
- Version
- Top entry
