Description
Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor distance depends on Fiberoptic Cables Used, 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open coll, 100 mA PNP, 250 mA NPN at 10-30 Vdc, 4 Pin M12 Connector, Fiberoptic
Eaton 15100AQD07 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
General
- Catalog Notes
- Sensing range is based on 6.6 feet (2 m) of source and detector fiber optic cable without lenses for a total length of 13.1 feet (4 m). Lenses will increase ranges. Note that as bulk fiber length increases; sensing range decreases.
- Certifications
- UL Recognized
- Compliances
- CE Marked
- Product Height
- 2.87 in
- Product Length/Depth
- .47 in
- Product Weight
- .1313 lb
- Product Width
- .71 in
- UPC
- 782113843742
- Warranty
- 3 year
Specifications
- Cable type
- Polyvinyl Chloride (PVC)
- Connection
- 4-pin M12 connector
- Contact configuration
- NPN and PNP open collector
- Contact Rating
- 100 mA PNP, 250 mA NPN at 10-30 Vdc
- Cord length
- 8 in
- Enclosure material
- Cable jacket: PVC
- Environmental rating
- NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
- Input voltage
- 10-30 Vdc
- LED indicator
- Output status: red
- Maximum DC current
- 100 mA PNP, 250 mA NPN
- Operating mode
- Fiber-optic
- Operating temperature - max
- 158 °F
- Operating temperature - min
- -40 °F
- Protection
- Auto reset short circuit
- Sensor type
- Fiberoptic
- Switch type
- Photoelectric
