Carlo Gavazzi EM27172DMV53X2SN
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Multi-load Three-phase Energy analyzer - Multi-load Energy analyzer, 160 to 240 V L-N277 to 415 V L-L, RS485 Modbus RTU
Carlo Gavazzi EM27172DMV53X2SN is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Approvals, marks, declarations
- CE (Europe) | cULus (North America)
- Calibrated
- Yes
- Communication port and protocol
- RS485 (Modbus RTU)
- Configuration software
- UCS desktop (PC)
- Degree of protection (IP)
- IP40
- Energy metering
- Consumption | Consumption and generation
- Energy type
- Effective power and blind power
- Frequency
- Min.50-Max.60
- 50Hz | 60Hz
- Main Filter
- 1-Phase | 3-Phase
- Measuring type load profile
- No
- Model
- Measurement transformer
- Monitored loads per meter
- 1-phase loads: up to 6 | 3-phase loads: up to 2
- Mounting method
- DRA (DIN-rail adapter)
- Multi-load sensor current inputs
- 60A | 100A | 200A | 400A
- Multi-load sensor type
- split core
- Nominal voltage (Un) L-L
- Min.277-Max.415
- Nominal voltage (Un) N-L
- Min.160-Max.240
- Number of positions total (counter)
- 7
- Pole type
- Four conductor
- Power supply
- Self power supply
- Product Depth
- 58
- Product Height
- 72
- Product Main Family
- Energy meters and analysers
- Product Main Family Group
- Multi-load metering
- Product Width
- 72
- Pulse output
- Optic
- Pulse rate
- Min.0.1-Max.100
- Rail mounting possible
- Yes
- Suitable for
- Purchase/supply
- Type of indication
- Digital
- Type of interface
- RS-485
- Type of meter
- Electronic
- Voltage inputs
- 2-wire, 220 V L-N | 2-wire, 230 V L-N | 2-wire, 240 V L-N | 4-wire, 220/380 V | 4-wire, 230/400 V | 4-wire, 240/415 V
- Wall mounting/direct mounting
- Yes
- Width in number of modular spacings
- 4
- With approval according to UL
- Yes
- With lock code
- Yes
