Description
Carlo Gavazzi DUA52C748 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- 1-phase ac/dc voltage
- Undervoltage
- 1-phase voltage range
- 12-24 Vdc
- Approvals, marks, declaration
- for Europe | for North America
- Depth
- 67.2
- Effective power
- No
- Height
- 81
- Housing
- mini-DIN-rail
- Hysteresis
- Yes
- Main Filter
- Mini DIN-rail
- Max. permitted delay-on energization time
- 0.2
- Max. permitted off-delay time
- 0.2
- Measuring range
- 48 V DC
- Number of contacts as change-over contact
- 1
- Output
- 1 x SPDT change-over contact
- 1 relay
- Over or under voltage detection
- No
- Over voltage detection
- No
- Product Main Family
- Monitoring relays
- Product Main Family Group
- 1-phase ac/dc voltage
- Rail mounting possible
- Yes
- Rated control supply voltage Us at DC
- Min.38-Max.58
- Setting method through NFC (Near Field Communication)
- No
- Step angle (cos phi)
- No
- Supply monitoring type
- Monitoring own supply
- Supply Voltage
- Self-powered
- Time delay
- No delay adjustment
- Transistor output
- No
- Type of electric connection
- Screw connection
- Type of output
- 1 SPDT relay
- Type of voltage
- DC
- Under voltage detection
- Yes
- Voltage type for actuating
- DC
- Wall mounting/direct mounting
- No
- Web Class
- 1-phase ac/dc voltage
- Width
- 17.5
- With approval according to UL
- Yes
- With detachable clamps
- No
