Carlo Gavazzi DEB71DM24A5
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Carlo Gavazzi DEB71DM24A5 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Approvals, marks, declaration
- for Europe | for North America
- Depth
- 65
- Earth leakage
- Adjustable input range
- Effective power
- No
- Error registration possible
- No
- Function
- For AC-current system
- Height
- 81
- Housing
- Din-Rail
- Indication of difference current
- Yes
- Leakage current value
- 0,03A | 0,03-5A
- Main Filter
- Mini DIN-rail
- Max. permitted delay-on energization time
- 5
- Measuring range
- 12-24 V DC
- Output
- 2 relays
- 2 x SPDT change-over contact
- Product Main Family
- Monitoring relays
- Product Main Family Group
- Earth leakage
- Rail mounting possible
- Yes
- Range
- 30 mA-5 A, adjustable
- Rated frequency
- Min.40-Max.70
- Setting method through NFC (Near Field Communication)
- No
- Step angle (cos phi)
- No
- Supply Voltage
- 24-240 V AC
- Time delay
- Delay on alarm
- Transistor output
- No
- Type of electric connection
- Screw connection
- Type of output
- 2 SPDT or 1 DPDT relays
- Wall mounting/direct mounting
- No
- Web Class
- Earth leakage
- Width
- 35.5
- With approval according to UL
- Yes
- With detachable clamps
- No
