Burndy YH3429
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Copper Compression H Tap, Tin Plated, Accommoding the following wire sizes - Run (Main): 500 KCMIL-4/0 AWG Class B,C, 373 KCMIL-4/0 AWG DLO, 350 KCMIL-4/0 AWG CLASS I, 4/0 AWG CLASS K, Tap 1: 250 KCMIL-1/0 AWG Class B,C, 4/0 AWG-1/0 AWG Class I, DLO, 4/0 AWG Class K, Tap 2: 1 AWG-6 AWG Class B,C, 1 AWG-8 AWG Class I, DLO, 8 AWG Class K, Tap 3: 8 AWG-14 AWG Class B,C, 8 AWG-14 AWG Class I, 8 AWG Class K. See sale drawing for metric wire size accommodatesCopper Compression H Tap, 500 KCMIL-250 KCMIL (Main), 250 KCMIL-4/0 AWG(Tap), Tin Plated
Burndy YH3429 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- CSA Approved
- Yes
- cULus
- No
- ETL
- No
- EU RoHS Indicator
- Yes
- UL Recognized
- No
Specifications
- Application
- Wire Tap
- ARRA Compliant
- Yes
- Base Unit of Measure
- EA
- Buy American Compliant
- Yes
- Carton - SCC-14 Next Lower Level Sub Pack
- 00781810013892
- Case - SCC-14 Next Lower Level Sub Pack
- 30781810013893
- Certification Agency
- Proposition 65
- Class Code
- B55
- Color Code
- Brown
- Conductor - Copper Flex G Run
- 4/0 AWG;250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil
- Conductor - Copper Flex G Run Range
- 4/0 AWG-500 kcmil
- Conductor - Copper Flex H Run
- 8 AWG;7 AWG;6 AWG;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil;300 kcmil;350 kcmil
- Conductor - Copper Flex H Run Range
- 8 AWG-350 kcmil
- Conductor - Copper Flex I Run
- 350 KCMIL-4/0 AWG
- Conductor - Copper Flex I Run Range
- 4/0 AWG-500 kcmil
- Conductor - Copper Flex I Tap
- 1/0;2/0;3/0;4/0;250
- Conductor - Copper Flex I Tap Range
- 4/0 AWG-1/0 AWG
- Conductor - Copper Flex K Run
- 4/0 AWG;250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil
- Conductor - Copper Flex K Run Range
- 4/0 AWG-500 kcmil
- Conductor - Copper Flex K Tap
- 1/0;2/0;3/0;4/0;250
- Conductor - Copper Flex K Tap Range
- 4/0 AWG
- Conductor - Copper Flex M Run
- 4/0 AWG;250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil
- Conductor - Copper Flex M Run Range
- 4/0 AWG-500 kcmil
- Conductor - Copper Flex M Tap
- 1/0;2/0;3/0;4/0;250
- Conductor - Copper Str Run
- 4/0 AWG;250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil
- Conductor - Copper Str Run Range
- 500 KCMIL-4/0 AWG
- Conductor - Copper Str Tap
- 1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil
- Conductor - Copper Str Tap Range
- 250 KCMIL-1/0 AWG
- Conductor - Material
- COPPER
- Conductor Type
- CODE/FLEX
- Connector Type
- H-TAP
- Country of Origin
- US
- Description - Invoice
- CU H-TAP 500-250 W/O COVER
- Description - Slang
- H TAP TIN PLATE
- Die Index
- 1104
- Dimension - Height inch
- 2.23 in
- Dimension - Length Overall inch
- 1.00 in
- Dimension - L Length Overall mm
- 25 mm
- Dimension - Strip Length inch
- 1-1/8
- Dimension - Width fraction
- 1.31 in
- Dimension - Width inch
- 2.23 in
- Each - Number of Sub Packs
- 1
- Each - Pack Description
- Each
- Each - Width
- 1.31 in
- Finish
- Tin-Plated
- Finish Type
- Tin-Plated
- Freight Class Code
- 16027000
- Harmonization Code
- 8535908040
- Image Actual Or Representative
- A
- Industry Standard(s)
- UL 486A-486B
- Lead Time
- 11 wk
- Lowest Level UOM
- Each
- Material
- COPPER
- MSDS Flag
- No
- Order Multiple
- 1 EA
- Package - Gross Weight per Pack
- 19.5 lb.
- Package - GTIN - Package
- 30781810013893
- Package Height
- 6.13 in
- Package Length
- 9.38 in
- Package - Number of Sub Packs
- 50
- Package - Pack Description
- Package
- Package Quantity
- 50 EA
- Package - SCC-14 Next Lower Level Sub Pack
- 00781810013892
- Package - Total Units
- 50 EA
- Package Weight
- 19.5 lb.
- Package Width
- 7.44 in
- Plated
- Y
- Plating Type
- Tin - Electro Plated
- Product Type
- RUN/TAP
- Special Features
- Features: Accommodates A Wide Range Of Run/Tap Copper Cable Combinations Including Both Flexible And Code Combinations, All (B/B, B/I, I/B, I/I) Combinations Acceptable: Each Connector Has Many Copper Cable Combination Applications Allowing Maximum Flexibility For The Design And Installation Of A System, Tap Grooves Function Independently Of Each Other, Use Of One Tap Is Required, Balance May Be Used Or Left Empty: Provides Maximum Design And Installation Flexibility, Color Code On The Connector Matches Installation Die: Provides Matched System For Fast And Easy Installation, Die Index Embossed On Connector After Completion Of Crimp: Permanent Inspectability Of Installed Connectors To Insure Consistently Reliable And Dependable Connections, Recommended Flame Retardant Type CFFR Insulating Covers Meet Oxygen Index 28 And UL94 V-O Requirements: A Complete Insulated UL Listed Installation Is Provided, Third Hand Constrains Conductors While Installer Completes Crimp, Included With Each Connector, Simplifies Installation, Reducing Installed Cost, Use PUADP-1 Adaptor With U Dies In Y46, Tools, Die Set Catalog Number, And (number Of Crimps): Y750 Tool, U1104M Die, (1), U1104 Die, (2), Y46 Tool, U1104M Die With PUADP-1 Adapter, (1), P1104 Die, (1), Color Code: Brown, Wire Strip Length: 1-1/8 IN, Flame Retardant Cover: CFN-FR, Die Index: 1104 Element A, Cover Packaged With Connector: No, Conductor Type: Run: Commercial Stranded Copper, Flexible Copper, Tap: Commercial Stranded Copper, Flexible Copper, Conductor Size (run - Range): 4/0 AWG - 500 KCMIL, Shape: H, Conductor Size (tap Range): 1/0 AWG - 250 KCMIL
- Standard
- UL 486A-486B
- Standard Package Quantity
- 50
- Standards - Industry Standards Met
- UL467
- Standards - RoHS Compliance Status
- CM
- Stock Indicator
- S - Shelf Stock
- Sub Brand
- CRIMPIT
- Sub Class Code
- B55BI1F
- Temperature Rating
- 194
- Trade Name
- CRIMPIT™
- Type
- Compression Taps
- UL Listed
- Yes
- Voltage - Maximum
- 35000
- Voltage Rating
- 35 kV
- Width
- 1.31 in
