Burndy YA26L3
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Copper Compression lug, 1 Hole w/ Inspection Window, 2/0 AWG, 5/16" Stud, Short Barrel, Tin Plated.Copper Compression Terminal
Burndy YA26L3 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- CSA Approved
- Yes
- cULus
- No
- ETL
- No
- EU RoHS Indicator
- Yes
- UL Recognized
- No
Specifications
- Application
- Wire Termination
- ARRA Compliant
- Yes
- Base Unit of Measure
- EA
- BOX SIZE
- 2.492x2.996x3.236 (in)
- Buy American Compliant
- Yes
- Carton - Gross Weight per Pack
- 0.600 lb.
- Carton - Number of Sub Packs
- 10
- Carton - Pack Description
- Carton
- Carton - SCC-14 Next Lower Level Sub Pack
- 00781810553787
- Carton - Total Units
- 10
- Case - SCC-14 Next Lower Level Sub Pack
- 30781810553788
- Certification Agency
- Proposition 65
- Class Code
- B55
- Color Code
- Black
- Conductor - Copper Str Navy Size
- 125 (61) Navy
- Conductor - Copper Str Navy Size Range
- 125 (61) Navy
- Conductor - Copper Str Size
- 2/0 AWG
- Conductor - Copper Str Size Range
- 2/0 AWG
- Conductor - Material
- COPPER
- Conductor Size
- 2/0 AWG
- Conductor Type
- CODE
- Connector Type
- STANDARD BARREL
- Country of Origin
- US
- Description - Invoice
- 2/0 CU 1-HOLE SHORT 5/16
- Description - Slang
- CU TERM CODE STD BBL TN
- Die Index
- 13
- Dimension - B Length fraction
- 15/16 in
- Dimension - B Length inch
- 0.94 in
- Dimension - Bolt Hole Size inch
- 0.33 in
- Dimension - Bolt Size fraction
- 5/16
- Dimension - Bolt Size inch
- 0.3125
- Dimension - D inch
- 0.70 in
- Dimension - Hole Size fraction
- 5/16
- Dimension - Hole Size inch
- 0.38
- Dimension - Hole Size mm
- 10 mm
- Dimension - Length Overall inch
- 2.06 in
- Dimension - L Length Overall mm
- 52 mm
- Dimension - N inch
- 0.34 in
- Dimension - Outside Diameter inch
- 0.56 in
- Dimension - Pad Width inch
- 0.83 in
- Dimension - Strip Length inch
- 1 in
- Dimension - Stud Size fraction
- 5/16
- Dimension - Stud Size inch
- 5/16
- Dimension - Z inch
- 0.36 in
- Each - Number of Sub Packs
- 1
- Each - Pack Description
- Each
- Each - Width
- 0.83 in
- Feature - Barrel Style
- Chamfered;Skived
- Feature - Barrel Type
- Standard
- Finish Type
- Tin-Plated
- Freight Class Code
- 16027000
- Harmonization Code
- 8535908020
- Image Actual Or Representative
- A
- Industry Standard(s)
- UL 486A-486B
- Lead Time
- 11 wk
- Lowest Level UOM
- Each
- Material
- COPPER
- MSDS Flag
- No
- Order Multiple
- 1 EA
- Package - Gross Weight per Pack
- 0.6 lb.
- Package - GTIN - Package
- 30781810553788
- Package Height
- 2.43 in
- Package Length
- 3.25 in
- Package - Number of Sub Packs
- 10
- Package - Pack Description
- Package
- Package Quantity
- 10 EA
- Package - SCC-14 Next Lower Level Sub Pack
- 00781810553787
- Package - Total Units
- 10 EA
- Package Weight
- 0.6 lb.
- Package Width
- 3.00 in
- Physical Attribute - Number of Holes
- 1
- Physical Attribute - Tongue Angle
- Straight
- Physical Attribute - Tongue Type
- Standard
- Plated
- Y
- Plating Type
- Tin - Electro Plated
- Product Type
- TERMINAL
- Replaced Catalog Number
- YA26L3
- Special Features
- Features: UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, Conductor Type: Commercial Stranded Copper, Die Index: 13, Tongue Angle: Straight, Wire Strip Length: 1 IN
- Standard
- UL 486A-486B
- Standard Package Quantity
- 10
- Standards - Industry Standards Met
- UL467
- Standards - RoHS Compliance Status
- CM
- Stock Indicator
- S - Shelf Stock
- Sub Brand
- HYLUG
- Sub Class Code
- B55BH0F
- Trade Name
- HYLUG™
- Type
- Standard Barrel, Tin Plated
- UL Listed
- Yes
- Voltage - Maximum
- 35000
- Voltage Rating
- 35 kV
- Width
- 0.83 in
