Burndy WCY52
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Wejtap Assembly , Installed With Yellow Booster, Sum of diameters: 1.190 (Max), 1.001 (Min).Wejtap Assembly, Installed With Yellow Booster, Sum of diameters: 1.190 (Max), 1.001 (Min)
Burndy WCY52 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- CSA Approved
- No
- cULus
- No
- ETL
- No
- EU RoHS Indicator
- Yes
- UL Recognized
- No
Specifications
- Application
- For use in tap applications using large run and tap conductor sizes
- ARRA Compliant
- No
- Base Unit of Measure
- EA
- Buy American Compliant
- No
- Carton - SCC-14 Next Lower Level Sub Pack
- 00781810874004
- Case - SCC-14 Next Lower Level Sub Pack
- 30781810874005
- Certification Agency
- Proposition 65
- Class Code
- B32
- Conductor - ACSR Str Run
- 4/0 (6/1) Penquin AWG;80 (8/1) Grouse kcmil;101.8 (12/7) Petrel kcmil;110.8 (12/7) Minorca kcmil;134.6 (12/7) Leghorn kcmil;159 (12/7) Guinea kcmil;176.9 (12/7) Dotterel kcmil;190.8 (12/7) Dorking kcmil;211.3 (12/7) Cochin kcmil;203.2 (16/9) Brahma kcmil;266.8 (18/1) Waxwing kcmil;266.8 (26/7) Owl kcmil;266.8 (26/7) Partridge kcmil;300.0 (26/7) Ostrich kcmil;336.4 (18/1) Merlin kcmil;336.4 (26/7) Linnet kcmil;336.4 (30/7) Oriole kcmil;397.5 (18/1) Chickadee kcmil;397.5 (24/7) Brant kcmil;397.5 (26/7) Ibis kcmil
- Conductor - ACSR Str Run Range
- 4/0 (6/1) Penquin AWG-397.5 (26/7) Ibis kcmil
- Conductor - ACSR Str Tap
- 1 (6/1) Robin AWG;1/0 (6/1) Raven AWG;2/0 (6/1) Quail AWG;3/0 (6/1) Pigeon AWG;4/0 (6/1) Penquin AWG;80 (8/1) Grouse kcmil;101.8 (12/7) Petrel kcmil;110.8 (12/7) Minorca kcmil;134.6 (12/7) Leghorn kcmil;159 (12/7) Guinea kcmil;176.9 (12/7) Dotterel kcmil;190.8 (12/7) Dorking kcmil;211.3 (12/7) Cochin kcmil;203.2 (16/9) Brahma kcmil;266.8 (18/1) Waxwing kcmil
- Conductor - ACSR Str Tap Range
- 1 (6/1) Robin AWG-266.8 (18/1) Waxwing kcmil
- Conductor - AL Str Run
- 4/0 AWG;250 kcmil;266 kcmil;300 kcmil;336 kcmil;350 kcmil;397 kcmil;400 kcmil;450 kcmil
- Conductor - AL Str Run Range
- 4/0 AWG-450 kcmil
- Conductor - AL Str Tap
- 1;1/0;2/0;3/0;4/0;250;266.8
- Conductor - AL Str Tap Range
- 1-266.8
- Conductor Type
- ACSR C Str-Run;AL C Str-Run;ACSR C Str-Tap;AL C Str-Tap
- Connector Type
- Tap
- Country of Origin
- MX
- Description - Invoice
- Conn ANSI CL:AA RUS,12.63 IN L,6.38 IN W
- Dimension - F Width Center to Center inch
- 3 in
- Dimension - G inch
- 1.37 in
- Each - Number of Sub Packs
- 1
- Each - Pack Description
- Each
- Each - Width
- 2.44 in
- Freight Class Code
- 16027000
- Harmonization Code
- 8535908040
- Image Actual Or Representative
- A
- Lead Time
- 11 wk
- Lowest Level UOM
- Each
- Material
- Aluminum
- MSDS Flag
- No
- Order Multiple
- 10 EA
- Package - Gross Weight per Pack
- 10 lb.
- Package - GTIN - Package
- 30781810874005
- Package Height
- 4.88 in
- Package Length
- 12.63 in
- Package - Number of Sub Packs
- 10
- Package - Pack Description
- Package
- Package Quantity
- 10 EA
- Package - SCC-14 Next Lower Level Sub Pack
- 00781810874004
- Package - Total Units
- 10 EA
- Package Weight
- 10 lb.
- Package Width
- 6.38 in
- Product Type
- Wejtap
- Special Features
- Features: With Yellow Power Booster, ANSI Class AA, Booster Color: Yellow, Conductor Size (tap - Mm): 9 - 15 SQ-MM, Installation Tool: WTRB Tool, Color Code: Yellow, Booster: WPBY Box 25, Conductor Type: Run: AAC, Tap: AAC, Copper, Cable Diameter Range (run): 0.537 - 0.75 IN, Conductor Size (run - Mm): 14 - 19 SQ-MM, Cable Diameter Range (tap): 0.364 - 0.588 IN
- Standard Package Quantity
- 10
- Standards - RoHS Compliance Status
- CM
- Stock Indicator
- S - Shelf Stock
- Sub Brand
- WEJTAP
- Sub Class Code
- B32B60F
- Trade Name
- WEJTAP™
- Type
- Wejtap Connector
- UL Listed
- No
- Width
- 2.44 in
