Description
VERSITAP™ Mechanical Parallel Clamp for Copper/Copperweld; Accommodates: Run: 500 - 1000 kcmil; Tap: #6 - #2 AWG.VERSITAP™ Mechanical Parallel Clamp for Copper/Copperweld
Burndy QPX442C is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- CSA Approved
- No
- cULus
- No
- ETL
- No
- UL Listed Direct Burial
- No
- UL Recognized
- No
Specifications
- Base Unit of Measure
- EA
- Carton - SCC-14 Next Lower Level Sub Pack
- 00781810344750
- Case - SCC-14 Next Lower Level Sub Pack
- 30781810344751
- Certification Agency
- Proposition 65
- Class Code
- B51
- Conductor - Copper Str Run
- 500 kcmil;550 kcmil;600 kcmil;700 kcmil;750 kcmil;800 kcmil;850 kcmil;900 kcmil;1000 kcmil
- Conductor - Copper Str Run Range
- 500 kcmil-1000 kcmil
- Conductor - Copper Str Tap
- 6 AWG;5 AWG;4 AWG;3 AWG;2 AWG
- Conductor - Copper Str Tap Range
- 6 AWG-2 AWG
- Conductor - CopperWeld Solid Run
- 6 AWG
- Conductor - CopperWeld Solid Run Range
- 6 AWG
- Conductor - CopperWeld Solid Tap
- 5 AWG
- Conductor - CopperWeld Solid Tap Range
- 5 AWG
- Conductor - CopperWeld Str Tap
- 8 A AWG;8 C AWG;8 D AWG;7 A AWG;7 D AWG;6 A AWG;6 C AWG;6 D AWG;5 A AWG;5 D AWG;5 P AWG;4 A AWG
- Conductor - CopperWeld Str Tap Range
- 8 A AWG-4 A AWG
- Conductor Type
- CU C Str-Run;CU Weld C Str-Run;CU Weld C Solid-Run;CU C Str-Tap;CU Weld C Str-Tap;CU Weld C Solid-Tap
- Connector Type
- Universal Clamp
- Country of Origin
- US
- Description - Slang
- VERSITAP QPX
- Dimension - Height fraction
- 2-11/16
- Dimension - Height inch
- 2.69
- Dimension - Length Overall inch
- 1.38 in
- Dimension - L Length Overall mm
- 35 mm
- Dimension - Width fraction
- 2-1/4 in
- Dimension - Width inch
- 2.22
- Dimension - Width mm
- 57 mm
- Freight Class Code
- 16027000
- Harmonization Code
- 8535908040
- Image Actual Or Representative
- A
- Industry Standard(s)
- UL486C
- Installation Torque Recommended in-lb
- 180 LBS/in
- Lead Time
- 12 wk
- Material
- Copper
- Material - Hardware
- DURIUM™ Silicon Bronze
- Package - GTIN - Package
- 30781810344751
- Package Quantity
- 3 EA
- Package - Total Units
- 3 EA
- Package Weight
- 0.000 lb.
- Plated
- N
- Plating Type
- Unplated
- Product Type
- RUN/TAP
- Rating - Minimum Voltage
- 600
- Standard Package Quantity
- 3
- Standards - Industry Standards Met
- UL486C
- Standards - RoHS Compliance Status
- EX
- Sub Class Code
- B51BG9F
- Temperature Rating
- 194
- Trade Name
- VERSITAP™
- UL Listed
- Yes
