Burndy NA18A2N
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Cu Alloy Terminal, 2 IPS Al or Cu, 230 kV, 2 Pad Holes, 1.75 IN Spacing, 7.50 IN L, 4.50 IN W, Bolted, Tube to Flat, 0.56 IN Hole Dia.Cu Alloy Terminal, 2 IPS Al or Cu, 230 kV, 2 Pad Holes, 1.75 IN Spacing, 7.50 IN L, 4.50 IN W, Bolted, Tube to Flat, 0.56 IN Hole Dia
Burndy NA18A2N is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- CSA Approved
- No
- cULus
- No
- ETL
- No
- UL Recognized
- No
Specifications
- Application
- Substation
- Base Unit of Measure
- EA
- Carton - SCC-14 Next Lower Level Sub Pack
- 00781810003756
- Case - SCC-14 Next Lower Level Sub Pack
- 30781810003757
- Certification Agency
- Proposition 65
- Clamping Element Design
- Body and Cap
- Class Code
- B21
- Conductor - AL Tube Std Size
- 2 IPS
- Conductor - AL Tube Std Size Range
- 2 IPS
- Conductor - Connection Combination
- Tube to Flat
- Conductor - Copper Tube Std Size
- 2 IPS IPS
- Conductor - Copper Tube Std Size Range
- 2 IPS IPS
- Conductor Type
- AL Tube Std-Size;CU Tube Std-Size
- Connector Type
- Terminal
- Country of Origin
- US
- Dimension - B Length fraction
- 4-1/4 in
- Dimension - B Length inch
- 4.25 in
- Dimension - D inch
- 3.00 in
- Dimension - F Width Center to Center inch
- 1.75 in
- Dimension - G inch
- 2.05 in
- Dimension - Height fraction
- 4-1/2
- Dimension - Height inch
- 4.47 in
- Dimension - Hole Size fraction
- 9/16
- Dimension - Length Overall inch
- 7.50 in
- Dimension - L Length Overall mm
- 191 mm
- Dimension - N inch
- 0.63 in
- Dimension - Pad Width inch
- 2.75 in
- Dimension - Width fraction
- 4-1/2 in
- Dimension - Width inch
- 4.50 in
- Dimension - Width mm
- 114 mm
- Freight Class Code
- 16027000
- Harmonization Code
- 8535908020
- Image Actual Or Representative
- A
- Installation Torque Recommended in-lb
- 480 LBS/in
- Lead Time
- 12 wk
- Material
- Aluminum Alloy
- Material - Hardware
- Aluminum
- Number Of Conductors
- 1
- One Wrench Installation
- Y
- Package - GTIN - Package
- 30781810003757
- Package Quantity
- 2 EA
- Package - Total Units
- 2 EA
- Package Weight
- 0.000 lb.
- Physical Attribute - Number of Holes
- 2
- Physical Attribute - Pad Alignment
- Offset
- Physical Attribute - Pad Configuration
- 2.75 x 3 - 2 holes
- Physical Attribute - Pad Orientation
- Straight
- Plated
- N
- Plating Type
- Unplated
- Product Type
- Mechanical
- Replaced Catalog Number
- NA18A2N
- Standard Package Quantity
- 2
- Standards - RoHS Compliance Status
- CM
- Sub Class Code
- B21B06F
- UL Listed
- No
