Burndy K22A39U2N
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Aluminum Universal Terminal, 2 Hole, 1/2" diameter stud holes spaced 1-3/4" on center (NEMA-spacing), tin plated.Aluminum Universal Terminal, 2 Hole, 1/2" diameter stud holes spaced 1-3/4" on center (NEMA-spacing), tin plated
Burndy K22A39U2N is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- CSA Approved
- Yes
- ETL
- No
Specifications
- Application
- Terminate multiple conductors onto equiment pads, panel boards, or switchgear
- Carton - SCC-14 Next Lower Level Sub Pack
- 00781810670163
- Case - SCC-14 Next Lower Level Sub Pack
- 30781810670164
- Certification Agency
- Proposition 65
- Class Code
- B51
- Conductor Type
- AL C Str-Size;CU C Str-Size
- Connector Type
- Stacked
- Country of Origin
- US
- Description - Invoice
- (4) 1/0-750; 2-HOLE NEMA
- Description - Slang
- Universal Terminals
- Dimension - Bolt Size fraction
- 1/2
- Dimension - Hole Size mm
- 0 mm
- Dimension - L Length Overall mm
- 0 mm
- Dimensions
- 5.34 in x 2.75 in x 3.00 in
- Dimension - Thread Size
- -
- Dimension - Width mm
- 0 mm
- Freight Class Code
- 16027000
- Harmonization Code
- 8535908020
- Height
- 3.00 in
- Image Actual Or Representative
- A
- Industry Standard(s)
- UL 486A-486B
- Lead Time
- 22 wk
- Length
- 5.34 in
- Material
- Aluminum
- MSDS Flag
- No
- Package - GTIN - Package
- 30781810670164
- Package Quantity
- 18 EA
- Package - Total Units
- 18 EA
- Package Weight
- 0.000 lb.
- Plated
- Y
- Plating Type
- Tin - Electro Plated
- Product Type
- TERMINAL
- Rating - Minimum Voltage
- 600
- Standard Package Quantity
- 1
- Standards - Industry Standards Met
- UL 486A-486B
- Standards - RoHS Compliance Status
- UI
- Sub Class Code
- B51BGGF
- Temperature Rating
- 194
- Type
- Bolted Lugs & Terminals
- Width
- 2.75 in
