Burndy DUW28AE
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Al Alloy Deadend Strain Clamp, With Pulling Eye, #1 - 4/0 AWG Al, #2 - 4/0 AWG ACSR.Al Alloy Deadend Strain Clamp, With Pulling Eye, #1 - 4/0 AWG Al, #2 - 4/0 AWG ACSR
Burndy DUW28AE is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- CSA Approved
- No
- cULus
- No
- ETL
- No
- UL Recognized
- No
Specifications
- Base Unit of Measure
- EA
- Carton - SCC-14 Next Lower Level Sub Pack
- 00781810013380
- Case - SCC-14 Next Lower Level Sub Pack
- 30781810013381
- Certification Agency
- Proposition 65
- Class Code
- B31
- Conductor - AAAC 5005 Size
- 77.47 (7) kcmil;123.3 (7) kcmil;155.4 (7) kcmil;195.7 (7) kcmil;246.9 (7) kcmil
- Conductor - AAAC 5005 Size Range
- 77.47 (7) kcmil-246.9 (7) kcmil
- Conductor - AAAC 6201 Size
- 77.47 (7) kcmil;123.3 (7) kcmil;155.4 (7) kcmil;195.7 (7) kcmil;246.9 (7) kcmil
- Conductor - AAAC 6201 Size Range
- 77.47 (7) kcmil-246.9 (7) kcmil
- Conductor - ACSR Str Size
- 2 (6/1) Sparrow AWG;2 (7/1) Sparate AWG;1 (6/1) Robin AWG;1/0 (6/1) Raven AWG;2/0 (6/1) Quail AWG;3/0 (6/1) Pigeon AWG;4/0 (6/1) Penquin AWG
- Conductor - ACSR Str Size Range
- 2 (6/1) Sparrow AWG-4/0 (6/1) Penquin AWG
- Conductor - AL Str Size
- 1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
- Conductor - AL Str Size Range
- 1 AWG-4/0 AWG
- Connector Type
- Deadend
- Country of Origin
- US
- Dimension - B Length fraction
- 5-4/21 in
- Dimension - B Length inch
- 5.19 in
- Dimension - Height fraction
- 2-3/50 in
- Dimension - Height inch
- 2.06 in
- Dimension - Hole Size fraction
- 22/25
- Dimension - Hole Size inch
- 0.88 in
- Dimension - Hole Size mm
- 22 mm
- Dimension - Length Overall inch
- 10.41 in
- Dimension - L Length Overall mm
- 264 mm
- Dimension - Width fraction
- 2-1/4 in
- Dimension - Width inch
- 2.25 in
- Dimension - Width mm
- 57 mm
- Dimension - Z inch
- 1.44 in
- Freight Class Code
- 16027000
- Harmonization Code
- 7616995190
- Image Actual Or Representative
- A
- Lead Time
- 12 wk
- Material
- Aluminum Alloy
- Material - Hardware
- Galvanized Steel
- Package - GTIN - Package
- 30781810013381
- Package Quantity
- 4 EA
- Package - Total Units
- 4 EA
- Package Weight
- 0.000 lb.
- Plated
- N
- Plating Type
- Unplated
- Prefilled Oxide Inhibitor
- N
- Product Type
- Mechanical
- Standard Package Quantity
- 4
- Standards - RoHS Compliance Status
- CM
- Sub Class Code
- B31B5CF
- UL Listed
- No
