Bryant DT5012W
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Timer Switches, Single Pole, 8.3A120/277V AC, 12 Hour Delay Time Out, WhiteTimer Switches, Single Pole, 8.3A120/277V AC, 12 Hour Delay Time Out, White
Bryant DT5012W is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Certifications
- EU RoHS Indicator
- No
Specifications
- Base Unit of Measure
- EA
- BOX SIZE
- 4.800x10.900x5.100 (in)
- Carton - Gross Weight per Pack
- 3.5 lb.
- Carton - Number of Sub Packs
- 10
- Carton - Pack Description
- Carton
- Carton - SCC-14 Next Lower Level Sub Pack
- 783585256474
- Carton - Total Units
- 10 EA
- Case - Total Units
- 50 EA
- Case Weight
- 15.000 lb.
- Color
- White
- Connectivity
- Wire Leads
- Control
- Pre-Set 5 Button Selection
- Country of Origin
- CN
- Description - Invoice
- TIMER 12 HR, 8.3A 120/277V , WHITE
- Dimensions
- 3.81 in x 1.75 in x 2.27 in
- Each - Pack Description
- Each
- Each - Width
- 2.400 in
- Freight Class Code
- 06168002
- Harmonization Code
- 8536509040
- Height
- 2.27 in
- Humidity
- 20% to 90% non-condensing relative humidity
- Image Actual Or Representative
- A
- Indicator
- Illuminates once time is selected
- Indicator(s) Type
- Red LED
- Industry Standard(s)
- cULus Listed To UL60730-1 And UL60730-2;Meets ASHRAE 90.1, and CEC Title 24 Compliant
- Length
- 3.81 in
- Lowest Level UOM
- Each
- Material
- Polycarbonate
- MSDS Flag
- No
- Operating Temperature
- 32°F to 122°F (0°C to 50°C) with rate of change not exceeding 20°F(11°C) per hour
- Performance
- Controls - 5 button selection - Preset time selection;Controls - LED Indicators - Illuminates once time is selected;Controls - OFF Switch - 6 seconds to 20 minutes (default set to 10 minutes);Electrical - Load Capacity - 120VAC 600W Incandescent, 5A Ballast, 5A CFL/LED 277V, Horsepower rating 1/6;Environmental - Operating Temperature - 32°F to 122°F (0°C to 50°C) with rate of change not exceeding 20°F(11°C) per hour;Environmental - Storage - -40°F to 150°F (-40°C to 65°C), 20% to 90% non condensing relative humidity
- Series
- Fixed Countdown
- Size
- 3.81 in x 1.75 in x 2.27 in
- Standard
- cULus Listed To UL60730-1 And UL60730-2;Meets ASHRAE 90.1, and CEC Title 24 Compliant
- Storage Temperature Range
- -40°F to 150°F (-40°C to 65°C)
- Timing Range
- OFF, 2, 4,8, 12 hours
- Type
- 12 Hours
- Voltage Rating
- 120/277 VAC
- Voltage Rating Description
- 120/277V AC
- Wattage
- 1000/1400 W
- Width
- 2.400 in
- Wire Length
- 6 in
- Wire Size
- #14 AWG
