Belden 1683ENH.00500
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Cat. 6A (500MHz), 4-Pair, U/UTP Unshielded, Premise Horizontal Cable, 23 AWG solid bare copper conductors, Polyethylene insulation, LSZH jacket1683ENH.00500 - Cat 6A Cable, U/UTP, LSZH, 4 Pair, AWG 23, Indoor CPR Eca
Belden 1683ENH.00500 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Applicable Environmental and Other Programs
- Environmental Space
- Indoor - Euroclass Eca
- EU RoHS Compliance Date (yyyy-mm-dd)
- 2015-08-25
Electrical Characteristics
- Segregation class according EN50174-2
- b
Flammability, LS0H, Toxicity Testing
- Amount of Halogen acc. to IEC 60754-1 & EN50267-1
- Zero
- Burning Load
- 745 kJ/m
- ISO/IEC Flammability
- IEC 60332-1-2
History
- Update and Revision
- Revision Number: 0.109 Revision Date: 12-11-2019
Mechanical Characteristics
- Bulk Cable Weight
- 50 kg/km
- Max Recommended Pulling Tension
- 80 N
Part Number
- Patent
- https://www.belden.com/resources/patents
Physical Characteristics (Overall)
- Bonded-Pair
- No
- Conductor Count
- 8
- Total Number of Pairs
- 4
Product Overview
- Suitable Applications
- Horizontal and building backbone cable; Support current and future Cat. 6a and 6 applications such as; 10GBase-T (10 Gigabit Ethernet), 1000Base-T (Gigabit Ethernet), 100 Base-T, 10 Base-T, FDDI and ATM
Specifications
- Color
- Blue
- Length
- 500 m
Standards
- ANSI Compliance
- ANSI/TIA 568.2-D (2018)
- CENELEC Compliance
- EN 50173-1 Ed. 3:2011
- CPR Euroclass
- Eca
- Data Category
- Category 6A
- IEEE Specification
- PoE: IEEE 802.3bt Type 1, Type 2, Type 3, Type 4
- ISO/IEC Compliance
- ISO/IEC 11801 Ed. 2.2:2002/A2:2010/C1:2011
Temperature Range
- Installation Temp Range
- 0°C To +50°C
- Operating Temp Range
- -30°C To +60°C
