ABB CL-513G
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Compact Pilot Light - Pilot light head - Green - Illuminated - Lamptype: LED 110-130V ACPILOT LIGHT CL-513G 110-130V a.c.
ABB CL-513G is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Classifications
- eClass
- V11.0 : 27371223
- E-Number (Sweden)
- 3711372
- Object Classification Code
- E
Dimensions
- Product Net Depth / Length
- 0.055 m
- Product Net Height
- 0.03 m
- Product Net Weight
- 0.022 kg
- Product Net Width
- 0.03 m
Environmental
- RoHS Date
- 0626 5
- RoHS Information
- 1SFC151012D0202
- RoHS Status
- Following EU Directive 2002/95/EC August 18, 2005 and amendment
- WEEE B2C / B2B
- Business To Business
- WEEE Category
- 5. Small Equipment (No External Dimension More Than 50 cm)
Ordering
- Customs Tariff Number
- 85369001
- Minimum Order Quantity
- 10 piece
Technical
- Actuator Type
- Pilot light head
- Ambient Air Temperature
- Operation -25 ... +70 °CStorage -30 ... +85 °C
- Color
- Green
- Connecting Capacity
- Flexible with Ferrule 1 x 0.75...2.5 mm²Flexible with Ferrule 2 x 0.75...2.5 mm²Flexible with Insulated Ferrule 1 x 0.75...2.5 mm²Flexible with Insulated Ferrule 2 x 0.75...2.5 mm²Flexible 1 x 0.75 ... 2.5 mm²Flexible 2 x 0.75 ... 2.5 mm²Solid 1 x 0.75...2.5 mm²Solid 2 x 0.75...2.5 mm²
- Connection Type
- Screw Clamp
- Degree of Protection
- Front IP66Front IP67Front IP69KTerminals IP20
- Enclosure Type NEMA
- Type1Type12Type13Type3RType4Type4X
- Illumination
- Illuminated
- Lamp Type
- LED 110-130V AC
- Pollution Degree
- 3
- Rated Frequency (f)
- Supply Circuit 50 / 60 Hz
- Rated Operational Voltage
- 110 ... 130 V AC
- Terminal Type
- Screw Terminals
- Tightening Torque
- 0.9 N·mControl Circuit 0.9 N·m
- Wire Stripping Length
- 8 mmControl Circuit 8 mm
Technical UL/CSA
- Connecting Capacity UL/CSA
- 1x 18...14 AWG2x 18...14 AWG
