ABB 1SNA295403R2500
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
1 stud terminal M10 x 31.5 mm 1.24 in, - Equipment: 1 bottom nut + 2 washers + 1 spring washer + 1 top nut.HD120/30.F8.31.1 - Stud terminal blocks - 1 stud M10 - Beige
ABB 1SNA295403R2500 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Classifications
- ETIM 4
- EC000897 - Feed-through terminal block
- ETIM 5
- EC000897 - Feed-through terminal block
- ETIM 6
- EC000897 - Feed-through terminal block
- Object Classification Code
- X
Container Information
- Package Level 1 Depth / Length
- 200 mm
- Package Level 1 EAN
- 3472592954035
- Package Level 1 Gross Weight
- 0.6 kg
- Package Level 1 Height
- 5 mm
- Package Level 1 Units
- 10 piece
- Package Level 1 Width
- 155 mm
- Package Level 2 Depth / Length
- 500 mm
- Package Level 2 Gross Weight
- 6 kg
- Package Level 2 Height
- 150 mm
- Package Level 2 Units
- 100 piece
- Package Level 2 Width
- 300 mm
- Package Level 3 Units
- 4800 piece
Dimensions
- Product Net Depth / Length
- 53.5 mm
- Product Net Height
- 50 mm
- Product Net Weight
- 60 g
- Product Net Width
- 30 mm
Environmental
- Ambient Air Temperature
- Operation -55 ... +110 °CStorage -55 ... +110 °C
Ordering
- Color
- Beige
- Customs Tariff Number
- 85369010
- Minimum Order Quantity
- 10 piece
Technical
- Connecting Capacity Main Circuit
- Stud / Flexible 1x 6 ... 120 mm²
- Connection Type
- Stud
- Function
- Feed-through
- Insulation Material
- Polyamide
- Mounting on DIN Rail
- Type 2 (21.8 x 8.2 mm Mounting Rail) acc. to NFC 93461TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
- Number of Levels
- 1
- Rated Cross-Section
- 120 mm²
- Rated Current (In)
- Main Circuit 269 A
- Rated Short-time Withstand Current (Icw)
- for 1 s 14400 A
- Rated Voltage (Ur)
- 750 V
- Spacing
- 30 mm
- Tightening Torque
- acc. IEC 60947-1 10 N·m
Technical UL/CSA
- Connecting Capacity UL/CSA
- Stranded 300 AWG
- Flammability According to UL94
- V-0
