Description
SWITCH-DISCONNECTOR TMAX XT1D 160 FIXED FOUR-POLE WITH FRONT TERMINALSXT1D 160 4p F F
ABB 1SDA068209R1 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
ABB EcoSolutions
- ABB EcoSolutions
- Yes
Additional Information
- Brand / Label
- ABB
- Connecting Capacity Main Circuit
- Busbar 45.5 ... 80 mm²
- Electrical Durability
- 120 cycles per hour8000 cycle
- Mechanical Durability
- 240 cycles per hour25000 cycle
- Number of Poles
- 4
- Opening Time
- CB with SOR 15 msCB with UVR 15 ms
- Order Multiple
- 1 piece
- Power Loss
- at Rated Operating Conditions per Pole 15 W
- Product Main Type
- SACE Tmax XT
- Product Name
- Moulded Case Circuit Breaker
- Product Type
- Switch Disconnector
- Rated Frequency (f)
- 50 / 60 Hz
- Rated Impulse Withstand Voltage (Uimp)
- 8 kV
- Rated Insulation Voltage (Ui)
- 800 V
- Rated Operational Voltage
- 690 V AC500 V DC
- Rated Short-time Withstand Current Low Voltage (Icw)
- for 1 s 2 kA
- Rated Uninterrupted Current (Iu)
- 160 A
- Recommended Screw Driver
- Main Circuit M6
- RoHS Date
- null
- Short-Circuit Performance Level
- D
- Standards
- IEC
- Sub-type
- XT1
- Terminal Connection Type
- Front
- Terminal Type
- Bolt
- Tightening Torque
- 6 N·m
- Version
- F
Circular Value
- Circular Design Principles Recyclability Rate
- Design for Closing Resource Loops - Standard EN45555 - 60.9 %
- Conflict Minerals Reporting Template (CMRT)
- 9AKK108467A5658
- End of Life Instructions
- 9AKK108468A2347
- Group Waste to Landfill Target
- UL 2799 Zero Waste To Landfill Validation available
- Toxic Substances Control Act - TSCA
- 9AKK108467A8326
Classifications
- eClass
- V11.1 : 27371403
- ETIM 9
- EC000216 - Switch disconnector (low voltage)
- Object Classification Code
- Q
- WEEE Category
- 5. Small Equipment (No External Dimension More Than 50 cm)
Dimensions
- Product Net Depth / Length
- 70 mm
- Product Net Height
- 130 mm
- Product Net Weight
- 1.4 kg
- Product Net Width
- 101.6 mm
Eco Transparency
- Environmental Product Declaration - EPD
- 9AKK108468A1890
Environmental
- Environmental Information
- 9AKK107991A8215 9AKK108467A6707
- REACH Declaration
- 9AKK108466A1425
- RoHS Information
- 9AKK108466A1424
- RoHS Status
- Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- SCIP
- e76d8a62-6cd4-4181-8912-0a56883546ae Italy (IT)
- Simplified SCIP
- b2d041bd-b2a7-4d64-acae-dc4c46fdc389 Poland (PL)5016ea2b-9840-4a51-b226-a3713eaa84f4 Sweden (SE)cb238410-e7ad-4c34-aec6-91cf5fb4d99e Germany (DE)118566cb-e785-4d81-9bbc-f5aa2cc5b11d France (FR)ff02e3a5-aa59-4b5c-b71b-5619f21b7e74 Germany (DE)e5a1ccd4-032e-4e4a-9fc8-ab88abbe4edc Germany (DE)fee23db7-252d-447c-bb37-1cb068cb9e2b France (FR)04440351-297e-44f2-97d8-37d251b1ee9e Netherlands (NL)cd93ab6c-9071-46ed-a485-cfed87940e62 Spain (ES)61b3f3a1-a6b0-4f54-994a-ca95439a5c37 Netherlands (NL)d32ed55f-def2-4660-8b2d-1a9fc38cde15 Poland (PL)c3267009-cd4a-43b2-936e-6c01b2817408 Norway (NO)4260e385-4ba2-45a2-a414-dca53f88fdf4 Finland (FI)3ae89504-1189-4571-a171-16be7ff4bebc Netherlands (NL)bd4ce42c-99c8-4fd5-b34a-3d492b63ffda Germany (DE)bda7c8d4-2cfd-4bd4-bf05-dffe4fa36c2e Denmark (DK)6af9f44d-b7a8-4f84-bdf7-c8ebd07ca418 Croatia (HR)bf18ce5b-1418-427a-8eb0-7380d4ae1cd2 Czech Republic (CZ)302cefe3-1517-4fd4-a984-31167cd51155 Poland (PL)47a8b693-5a3f-445a-8301-f06408a7b705 Netherlands (NL)c1b87025-54f0-4128-987e-748b70888a2a Netherlands (NL)5504494d-10bf-47f7-a4a5-c5170aa6f279 Estonia (EE)9feb07a0-b8ec-452c-9a31-9e342abac6f2 Greece (GR)36a3cb3c-0936-43a6-86c6-3db7ccdfa0e4 Portugal (PT)1271e950-36c2-4203-b143-2024d2f02d53 Bulgaria (BG)d283c17e-b22c-4ef5-ba2c-361625361758 Sweden (SE)
Ordering
- Customs Tariff Number
- 85362090
- Minimum Order Quantity
- 1 piece
- Order Code US and Canada
- XT1DE4160DFF000XXX
