ABB 1SDA067836R1
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
C.BREAKER TMAX XT2S 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP-LS/I R 100 AXT2S 160 Ekip LS/I In=100A 4p F F
ABB 1SDA067836R1 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
ABB EcoSolutions
- ABB EcoSolutions
- Yes
Additional Information
- CAD Dimensional Drawing
- 1SDH002230A1002
- Circuit Breaker Type to be Associated
- Power Distribution
- Connecting Capacity Main Circuit
- Busbar 32.5..100 mm²
- Current Type
- AC
- Electrical Durability
- 120 cycles per hour8000 cycle
- Mechanical Durability
- 240 cycles per hour25000 cycle
- Number of Poles
- 4
- Opening Time
- CB with SOR 15 msCB with UVR 15 ms
- Order Multiple
- 1 piece
- Power Loss
- at Rated Operating Conditions per Pole 4.2 W
- Product Main Type
- SACE Tmax XT
- Product Name
- Moulded Case Circuit Breaker
- Product Type
- Automatic Circuit Breaker
- Rated Current (In)
- 100 A
- Rated Frequency (f)
- 50 / 60 Hz
- Rated Impulse Withstand Voltage (Uimp)
- 8 kV
- Rated Insulation Voltage (Ui)
- 1000 V
- Rated Operational Voltage
- 690 V AC
- Rated Service Short-Circuit Breaking Capacity (Ics)
- (220 V AC) 85 kA(230 V AC) 85 kA(240 V AC) 85 kA(380 V AC) 50 kA(415 V AC) 50 kA(440 V AC) 50 kA(500 V AC) 36 kA(525 V AC) 25 kA(690 V AC) 12 kA
- Rated Ultimate Short-Circuit Breaking Capacity (Icu)
- (220 V AC) 85 kA(230 V AC) 85 kA(240 V AC) 85 kA(380 V AC) 50 kA(415 V AC) 50 kA(440 V AC) 50 kA(500 V AC) 36 kA(525 V AC) 25 kA(690 V AC) 12 kA
- Rated Uninterrupted Current (Iu)
- 160 A
- Rated Voltage (Ur)
- 690 V
- Recommended Screw Driver
- Main Circuit M6
- Release
- Ekip LS/I
- Release Type
- EL
- Short-Circuit Performance Level
- S
- Standards
- IEC
- Sub-type
- XT2
- Terminal Connection Type
- Front
- Terminal Type
- Bolt
- Tightening Torque
- 6 N·m
- Version
- F
Circular Value
- Circular Design Principles Recyclability Rate
- Design for Closing Resource Loops - Standard EN45555 - 58.1 %
- Conflict Minerals Reporting Template (CMRT)
- 9AKK108467A5658
- End of Life Instructions
- 9AKK108468A2349
- Group Waste to Landfill Target
- UL 2799 Zero Waste To Landfill Validation available
- Toxic Substances Control Act - TSCA
- 9AKK108467A8326
Classifications
- eClass
- V11.1 : 27370409
- ETIM 9
- EC000228 - Power circuit-breaker for trafo/generator/installation protection
- Object Classification Code
- Q
- WEEE Category
- 5. Small Equipment (No External Dimension More Than 50 cm)
Dimensions
- Product Net Depth / Length
- 82.5 mm
- Product Net Height
- 130 mm
- Product Net Weight
- 1.6 kg
- Product Net Width
- 120 mm
Eco Transparency
- Environmental Product Declaration - EPD
- 9AKK108468A1897
Environmental
- Environmental Information
- 9AKK107991A8215 9AKK108467A6707
- REACH Declaration
- 9AKK108466A1425
- RoHS Information
- 9AKK108466A1424
- RoHS Status
- Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- SCIP
- 9eb1504a-7a1b-469a-9aea-3db985751c11 Italy (IT)
- Simplified SCIP
- 78bf8f35-7905-44e2-828c-ff4d8a630123 Finland (FI)8f363337-dcd9-44fd-8990-a47c8aedddd5 Netherlands (NL)c4899fe1-7fa7-4597-a162-ab78ce2523ba Germany (DE)c0481b7d-5ae4-4869-81b0-5b14582752c4 Netherlands (NL)f58445ab-1933-4e1a-b4e1-2df06d3c8131 Netherlands (NL)69220fe9-baa2-4f4a-8b7a-b6d376f940b4 Estonia (EE)1d386019-ef0a-4bbe-8fe0-4d496c524448 Greece (GR)fac32ff8-d970-4b53-8f17-b70e2bd6a823 Portugal (PT)f51e105f-7721-4fff-af4a-41c6f8f3d6d5 Denmark (DK)bc45ec65-ae2c-44f7-ae1f-5902a7c34e62 Germany (DE)341cd88b-ce0f-48df-b92e-6b8cf4ab40b1 Croatia (HR)4a2050ae-16e2-45a2-86b2-fa0b6923b28c Czech Republic (CZ)0cc43524-6de8-45ba-a48c-40ef2e0a44d1 Poland (PL)ed92500a-2d5d-4200-9972-907f3fb6ece4 Germany (DE)f0c18254-d5d1-4128-bcc9-96be89240a10 Germany (DE)95a055a7-0edd-4b44-b135-e2c68a9ca3b4 France (FR)5fc5c5ff-3c2a-4243-af4a-054bc8357e9c Netherlands (NL)95da6abf-dbb7-4ae4-b19c-f0e32bf86233 Spain (ES)c8db6651-c8f9-4361-aaf2-e7b1db0447f7 Netherlands (NL)cd02d596-face-4b90-af46-d01b1e87577f Bulgaria (BG)58e82de9-91b4-42ee-8e76-d23df4aa040a Sweden (SE)c36bb6ee-8731-4a27-b3b9-a4ae587f86ad Poland (PL)571835d9-c0ac-4957-ab54-a6984e860ac9 France (FR)6d2cebb8-ed94-4b4a-b269-89c8f4ac75fb Sweden (SE)01647068-fc96-483a-96a8-616eb5c46cab Poland (PL)35506c41-38be-4e1c-8999-e8ab3bd5d390 Norway (NO)
Ordering
- Customs Tariff Number
- 85362090
- E-Number (Finland)
- 3640591
- E-Number (Sweden)
- 3182037
- Minimum Order Quantity
- 1 piece
- Order Code US and Canada
- XT2SE4100EFF000XXX
