ABB 1SDA067556R1
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
C.BREAKER TMAX XT2S 160 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 63 I3=315...630 AXT2S 160 TMA 63-630 3p F F
ABB 1SDA067556R1 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
ABB EcoSolutions
- ABB EcoSolutions
- Yes
Additional Information
- CAD Dimensional Drawing
- 1SDH002230A1001
- Circuit Breaker Type to be Associated
- Power Distribution
- Connecting Capacity Main Circuit
- Busbar 32.5..100 mm²
- Current Type
- AC/DC
- Electrical Durability
- 120 cycles per hour8000 cycle
- Mechanical Durability
- 240 cycles per hour25000 cycle
- Number of Poles
- 3
- Opening Time
- CB with SOR 15 msCB with UVR 15 ms
- Order Multiple
- 1 piece
- Power Loss
- at Rated Operating Conditions per Pole 4.85 W
- Product Main Type
- SACE Tmax XT
- Product Name
- Moulded Case Circuit Breaker
- Product Type
- Automatic Circuit Breaker
- Rated Current (In)
- 63 A
- Rated Frequency (f)
- 50 / 60 Hz
- Rated Impulse Withstand Voltage (Uimp)
- 8 kV
- Rated Instantaneous Short-Circuit Current Setting (Ii)
- 300…630 A
- Rated Insulation Voltage (Ui)
- 1000 V
- Rated Operational Voltage
- 690 V AC500 V DC
- Rated Service Short-Circuit Breaking Capacity (Ics)
- (220 V AC) 85 kA(230 V AC) 85 kA(240 V AC) 85 kA(380 V AC) 50 kA(415 V AC) 50 kA(440 V AC) 50 kA(500 V AC) 36 kA(525 V AC) 25 kA(690 V AC) 12 kA(250 V DC) 2 Poles in Series 50 kA(500 V DC) 3 Poles in Series 50 kA
- Rated Ultimate Short-Circuit Breaking Capacity (Icu)
- (220 V AC) 85 kA(230 V AC) 85 kA(240 V AC) 85 kA(380 V AC) 50 kA(415 V AC) 50 kA(440 V AC) 50 kA(500 V AC) 36 kA(525 V AC) 25 kA(690 V AC) 12 kA(250 V DC) 2 Poles in Series 50 kA(500 V DC) 3 Poles in Series 50 kA
- Rated Uninterrupted Current (Iu)
- 160 A
- Rated Voltage (Ur)
- 690 V
- Recommended Screw Driver
- Main Circuit M6
- Release
- TMA
- Release Type
- TM
- Setting Range
- 44.1...63 A
- Short-Circuit Performance Level
- S
- Standards
- IEC
- Sub-type
- XT2
- Terminal Connection Type
- Front
- Terminal Type
- Bolt
- Tightening Torque
- 6 N·m
- Version
- F
Circular Value
- Circular Design Principles Recyclability Rate
- Design for Closing Resource Loops - Standard EN45555 - 58.1 %
- Conflict Minerals Reporting Template (CMRT)
- 9AKK108467A5658
- End of Life Instructions
- 9AKK108468A2348
- Group Waste to Landfill Target
- UL 2799 Zero Waste To Landfill Validation available
- Toxic Substances Control Act - TSCA
- 9AKK108467A8326
Classifications
- eClass
- V11.1 : 27370409
- ETIM 9
- EC000228 - Power circuit-breaker for trafo/generator/installation protection
- Object Classification Code
- Q
- WEEE Category
- 5. Small Equipment (No External Dimension More Than 50 cm)
Dimensions
- Product Net Depth / Length
- 82.5 mm
- Product Net Height
- 130 mm
- Product Net Weight
- 1.4 kg
- Product Net Width
- 90 mm
Eco Transparency
- Environmental Product Declaration - EPD
- 9AKK108468A1891
Environmental
- Environmental Information
- 9AKK107991A8215 9AKK108467A6707
- REACH Declaration
- 9AKK108466A1425
- RoHS Information
- 9AKK108466A1424
- RoHS Status
- Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- SCIP
- 1356d4aa-8ac0-4c90-a0a6-7bd20dbf382e Italy (IT)
- Simplified SCIP
- 904e26e1-b4f8-446c-bcad-9aa8f98e42b9 Netherlands (NL)1664f057-cbae-4159-8779-ec95f143db2a Spain (ES)4fc7a468-c5ba-4bff-a584-8685ec52f288 Netherlands (NL)b44ff0ce-ec9f-428c-9384-adbfb0d3a081 Bulgaria (BG)4b295e8e-2540-41ab-8e3b-baee28071515 Sweden (SE)00fba872-10c1-45b1-9422-6fa193bcf6c2 Poland (PL)424f2299-cff1-4f85-8472-b9b9d8454dcd France (FR)3389ba5f-3328-46ab-b5a0-db2105f1e8e4 Croatia (HR)1dc918cc-06e4-46de-9766-201bea1beb1b Czech Republic (CZ)ad59485a-8d3c-4d59-93ba-2c60c2a7a508 Poland (PL)8b836f51-1f94-497d-a2de-1f6e8d352126 Sweden (SE)761e6038-a9f8-492f-a604-350f95784e3e Germany (DE)8ce021f5-d2fc-4312-bce1-35abcf47b93f Germany (DE)19ca41ae-ae94-4c94-8b1c-3db95f936525 France (FR)fb53d5fa-faa9-4ad6-a19c-240b80f79df6 Poland (PL)34d65c78-b470-4060-952a-7b62093cb521 Norway (NO)a93a0f59-3251-4210-ae7d-9294ba2854fa Finland (FI)b13374ee-6f72-4e10-ae12-33e81bcfc856 Netherlands (NL)aafcd53f-4f76-4a48-991b-3c70373b814f Germany (DE)08750b2c-f6f5-4cbc-af6e-920b98268ae9 Netherlands (NL)8699cdd4-d2d2-46a9-8bf6-ca7a24c69be5 Netherlands (NL)a49b2555-f610-49c5-be8a-a6368bfb46c1 Estonia (EE)e34dc943-512d-492d-8de5-8df021f436d6 Greece (GR)f8083088-0978-4053-95e8-05bd971aba66 Portugal (PT)96c89ff8-eb84-4285-bbd1-3879d6bc3b49 Denmark (DK)7de00697-df77-43ea-8dfd-a6576ad93b54 Germany (DE)
